19" 24 Port Unloaded Patch Panel | Staggered Design | Rear Support Bar by Certech
19" patch panel with 24 unloaded ports and staggered design—ideal for data centers and server rooms. Built for efficient cable management, with rear support bar for enhanced organization.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: CERTECH 1RU 19" 24 Port Unloaded Staggered Patch Panel, with Rear Support Bar
Brand: Certech
SKU: PP24UK-STG
Alternatively Known As: 19" Patch Panel, 24 Port Patch Panel, Unloaded Patch Panel, Staggered Patch Panel
Technical Specifications
- Material: 1.5mm SPCC, coated black for the panel and support bar; ABS, UL94V-0 for the bracket.
- Installation Temperature: 0 to 50 degrees Celsius.
- Storage Temperature: -40 to 70 degrees Celsius.
- Operating Temperature: -10 to 60 degrees Celsius.
- Accepts CERTECH keystone jack JKC6ATLBK.
- Dimensions (H x L x W): 44mm x 150mm x 482mm
- Weight: 1.5 kg
Key Features
- Extensive AXT (Alien Cross Talk) suppression through staggered port design.
- ETL verified ANSI/568.2-D Cat6A component & 4-connector channel including AXT tested with the CERTECH Cat6A UTP keystone jack.
- Snap-in support bar for rear cable management.
Professional Installation Requirements
- Professional installation is recommended for optimal performance and compliance with standards.
Applications
- Data centers and server rooms
- Telecommunications and networking installations
- Commercial and residential structured cabling systems
Standards & Compliance
- Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
- Designed for efficient cable management, reducing clutter and improving airflow in networking environments.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The CERTECH 1RU 19" 24 Port Unloaded Staggered Patch Panel is available now for immediate purchase. Ideal for structured cabling applications.
