1kVA 0.9kW Online UPS 2 Battery Banks Rack Tower Enduro
Enduro 1kVA 0.9kW online double conversion UPS features 2 battery banks and rack or tower mounting. Ideal for servers and sensitive IT loads.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Enduro EN1000 UPS, Enduro 1000VA Online UPS, True Online Double-Conversion UPS, Rackmount UPS
Technical Specifications
- Rated Capacity: 1000VA / 900W
- Topology: True online double conversion
- Output Waveform: Pure sine wave
- Input Voltage: 184–276V AC
- Output Voltage: 230V ±2%, user settable
- Output Power Factor: 0.9
- Input Power Factor: ≥0.98
- Transfer Time: 0 seconds
- Output Frequency: 50Hz ±0.1Hz
- Battery Type: Sealed lead-acid rechargeable batteries
- Battery Configuration: 3 x 12V 9Ah internal batteries; compatible with extended battery modules
- Recharge Time: 6–8 hours to 90%
- Communication: USB and RS-232 standard
- Expansion: Optional SNMP and relay cards
- Output Sockets: 2 x Australian 10A sockets and 1 x IEC 15A socket
- Display: LCD status display with load, battery, input, output and operating indications
- Protection: Surge, short-circuit, overload and resettable fuse protection
- Operating Temperature: 0–40°C
- Relative Humidity: 0–95%, non-condensing
- Noise Level: Less than 50dB at 1m
- Installation Format: 2RU rackmount or tower
- Runtime: Approximately 8 minutes at 900W load under standard battery configuration
- Dimensions (H x L x W): 87mm x 430mm x 440mm
- Weight: 15.1 kg
Key Features
- True online double-conversion technology for continuous power conditioning
- Pure sinewave output suitable for servers and sensitive electronic equipment
- Zero transfer time between mains and battery operation
- Rack or tower mounting for flexible installation
- Expandable runtime using compatible external battery modules
- Interactive LCD monitoring display
- USB and RS-232 communications included
- Optional SNMP and relay-card connectivity
- Emergency power-off input
- Generator compatible
- Suitable for servers, computers, telecommunications, surveillance, point-of-sale and industrial equipment
Professional Installation Requirements
- Installation and commissioning should be performed by suitably qualified electrical or UPS personnel. The unit contains hazardous mains and battery voltages; provide appropriate ventilation, earthing, clearances and access for battery servicing in accordance with the installation manual and applicable Australian electrical requirements.
Applications
- Server racks and network equipment
- Telecommunications systems
- Computer and data-processing equipment
- Security and camera-surveillance systems
- Point-of-sale systems
- Industrial control and automation equipment
- Sensitive electronic loads requiring continuous conditioned power
Standards & Compliance
- AS 62040.1 for uninterruptible power system safety requirements
Environmental Benefits
- Rechargeable sealed lead-acid batteries can be replaced and recycled through appropriate battery-recycling channels
- ECO operating mode can reduce energy consumption and heat generation when suitable for the connected load
- Runtime expansion can extend service life and reduce premature equipment replacement
- Continuous voltage regulation and surge protection can help extend the operating life of connected IT equipment
Warranty Information
Standard PSS Distributors warranty: 2-year return-to-base warranty from the original purchase date, covering defects in materials and workmanship subject to the published warranty terms. Transport costs are generally excluded.
Available Now
Available through ENDURO/PSS and authorised Australian distributors; confirm current stock and lead time before ordering.
UPS Sizing Calculator
This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
