1kVA 0.9kW Online UPS 3 Battery Banks Rack Tower Enduro

BRAND: CABAC
SKU: EN1-3-RT
$4,129.80 List price: $5,506.50
+ −
30 Days Return Electricians Unlock Trade Access
Enduro 1kVA 0.9kW online double conversion UPS features 3 battery banks and rack or tower mounting. Ideal for servers and sensitive IT loads.

Alternatively Known As: ENDURO EN1000 UPS, 1000VA Online UPS, 900W Rack/Tower UPS, Pure Sinewave UPS

Technical Specifications
  • Model: EN1000
  • Capacity: 1kVA / 900W
  • Topology: Online double conversion
  • Input Voltage Range: 230V ±20%
  • Input Frequency Range: 45–65Hz
  • Phase: Single phase
  • Input Power Factor: ≥0.98
  • Output Voltage: 230V AC ±2%, user-settable
  • Output Frequency in Battery Mode: 50Hz ±0.1Hz
  • Output Power Factor: 0.9
  • Waveform: Pure sinewave
  • Total Harmonic Distortion: ≤3% linear load; ≤5% non-linear load
  • Input Connection: IEC C14 10A
  • Output Connections: 2 x Australian 3-pin sockets, including critical and non-critical outlets
  • Battery Configuration: 3 x 12V 9Ah sealed lead-acid batteries
  • Rated Battery Voltage: 36V
  • Recharge Time to 90%: Approximately 5 hours
  • Battery Charging: Intelligent three-stage charging
  • Communications: USB and RS-232
  • Optional Management: SNMP and relay card support
  • Protection: Resettable circuit breaker, surge protection, short-circuit protection and emergency power off
  • Operating Temperature: 0–40°C
  • Operating Humidity: 0–95% non-condensing
  • Noise Level: Less than 50dB at 1m
  • Rack Height: 2RU
  • Dimensions (H x L x W): 86.5mm x 430mm x 440mm
  • Weight: 15.1 kg
Key Features
  • Online double-conversion protection for sensitive IT and electronic loads
  • Pure sinewave output with zero transfer time
  • Supports rack or tower installation
  • Interactive LCD for load, battery, input, output and operating-status monitoring
  • Three internal 12V 9Ah sealed lead-acid batteries
  • Runtime expandable with up to four compatible external battery modules
  • USB and RS-232 communications included
  • Optional SNMP and relay-card monitoring
  • Emergency power off function
  • Generator compatible
  • RJ45 network, fax and modem surge protection
Professional Installation Requirements
  • Installation, commissioning, battery replacement and servicing should be carried out by suitably qualified electrical or UPS service personnel. Follow the manufacturer's instructions and applicable Australian electrical installation requirements, including correct earthing, ventilation and battery handling.
Applications
  • Servers and server racks
  • Network and telecommunications equipment
  • Point-of-sale systems
  • Computer workstations
  • Security and camera surveillance systems
  • Telephone systems
  • Industrial control and sensitive electronic equipment
Standards & Compliance
  • AS 62040.1:2019 – Uninterruptible power systems, general and safety requirements
  • AS IEC 62040.2:2019 – Uninterruptible power systems, electromagnetic compatibility requirements
  • AS IEC 62040.3 – Uninterruptible power systems, performance and test requirements
  • AS/NZS 3000:2018 – Electrical installations, where connected as part of a building electrical installation
Environmental Benefits
  • Sealed lead-acid batteries can be recovered and recycled through approved battery-recycling channels
  • Replaceable battery architecture can extend the service life of the UPS and reduce electronic waste
  • Online power conditioning helps protect connected equipment and reduce premature component replacement
  • High normal-mode efficiency of at least 89% helps limit operating energy losses
Warranty Information

Standard PSS Distributors return-to-base warranty: 2 years from the original purchase date, subject to proof of purchase and the published warranty conditions. Transportation costs are generally excluded; battery coverage and exclusions should be confirmed for the specific supply.

Available Now

Available through ENDURO/PSS Distributors and authorised Australian distributors; confirm current stock and lead time before ordering.

UPS Sizing Calculator




This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
