2-Pole 40A Modular Switch | Red Toggle | Compact Design | High Durability by Hager
2-pole modular switch with 40A rating and red toggle—ideal for residential and commercial electrical systems. Built for high durability with 60,000 mechanical operations and compact design for easy installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 2-pole, 40A Modular Switch with Red Toggle
Brand: Hager
SKU: SBR240
Alternatively Known As: Hager 2P Modular Switch
Technical Specifications
- Number of poles: 2
- Rated current: 40 A
- Breaking capacity 400 V AC23A: 846 A
- Rated conditional short-circuit current Icc with gl-gG fuses: 0.60 kA
- Acceptable current rating AC21 category A: 40 A
- Rated short-circuit making capacity Icm under 415 V AC: 0.84 kA
- Rated operational voltage Ue: 400 V AC
- Type voltage supply: AC
- Ingress Protection (IP) class: IP20
- Frequency: 50-60 Hz
- Height: 83 mm
- Width: 35 mm
- Depth: 68 mm
- Number of NO contacts: 2
- Operating temperature: -20 to 70 °C
- Cross-section flexible conductor: 2.5 - 16 mm²
- Electrical durability at nominal load in AC21: 5000
- Power loss per pole at In: 1.10 W
- Dimensions (H x L x W): 83mm x 68mm x 35mm
- Weight: 0.2 kg
Key Features
- Red toggle for clear visibility
- Compact modular design
- High durability with 60,000 mechanical operations
- Wide operating temperature range
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended.
Applications
- Residential electrical installations
- Commercial electrical systems
Standards & Compliance
- IEC 60947-3 compliance
Environmental Benefits
- Long life reduces replacement frequency
- Efficient power loss management
Warranty Information
2 years warranty against manufacturing defects.
Available Now
The 2-pole, 40A Modular Switch with Red Toggle is available for immediate purchase. Ideal for residential and commercial electrical applications.
