200A AC Clamp Meter | CAT IV 600V Safety Rating | Large Backlit Display by Majortech
The 200A AC Clamp Meter features a CAT IV 600V safety rating and a large backlit LCD display, making it ideal for industrial and electrical maintenance applications. With the ability to measure AC and DC voltage up to 1000V and a clamp jaw opening of 16mm, it’s perfect for electricians and technicians needing accurate readings in tight spaces.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 200A AC Clamp Meter | CAT IV 600V Safety Rating | Large Backlit Display by Majortech
Brand: Majortech
SKU: MT700
Alternatively Known As: Digital Clamp Meter, AC Current Clamp Meter, Electrical Clamp Meter, MT700 Clamp Meter
Technical Specifications
- Function: DC Voltage, Range: 6V-1000V, Resolution: 1V, Accuracy: ±(3.0% + 5 Digits)
- Function: AC Voltage, Range: 6V-1000V, Resolution: 1V, Accuracy: ±(3.0% + 5 Digits)
- Function: Resistance, Range: 0 – 1999Ω, Resolution: 1Ω, Accuracy: ±(5% + 10 Digits)
- Clamp Jaw Opening: 16mm
- Display: Large backlit negative LCD
- Safety Rating: CAT IV 600V
- Count: 2000
- Dimensions (H x L x W): 180mm x 40mm x 70mm
- Weight: 0.3 kg
Key Features
- CAT IV 600V safety rating
- 2000 count 200A AC digital clamp meter
- Large backlit negative LCD display with simultaneous current and voltage readings
- Clamp jaw opening of 16mm for easy wire access
- Measures AC and DC voltage up to 1000V
- Resistance measurement capability
- Rotary Field Indication
- Continuity buzzer
- Data hold function
- Built-in flashlight
- Non-Contact Voltage detection
- Rugged double moulded rubber housing for heavy duty use
Professional Installation Requirements
- No professional installation required; designed for use by qualified electricians and technicians.
Applications
- Industrial: Mining and heavy industry electrical measurements
- Electrical: Current and voltage measurement in crowded or tight cable areas
- General: Electrical troubleshooting and maintenance
Standards & Compliance
- AS/NZS 61010 – Safety requirements for electrical equipment for measurement, control, and laboratory use
Environmental Benefits
- Helps reduce energy waste by enabling accurate electrical measurements and diagnostics
- Durable design reduces need for frequent replacements
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Majortech MT700 200A AC Clamp Meter is available now for immediate purchase. Ideal for industrial, mining, and electrical maintenance applications.
