22kW 3P Contactor | 1NO+1NC Auxiliary Contacts | 240VAC Coil | by Clipsal
The 22kW 3P Contactor with 1NO+1NC auxiliary contacts is designed for robust motor control in industrial automation. Operating at a coil voltage of 240VAC, this compact and reliable contactor is perfect for switching lighting circuits, HVAC systems, and general power distribution. Built for durability, it ensures efficient energy management and supports automation to reduce manual intervention.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 22kW 3P Contactor | 1NO+1NC Auxiliary Contacts | 240VAC Coil | by Clipsal
Brand: Clipsal
SKU: SCHLC1D40U7
Alternatively Known As: Clipsal 22kW Contactor, 3 Pole Contactor 240VAC, SCHLC1D40U7, Industrial Motor Contactor, Clipsal LC1D40U7
Technical Specifications
- Rated operational power: 22kW (AC-3, 400V)
- Number of poles: 3
- Auxiliary contacts: 1 NO + 1 NC
- Coil voltage: 240VAC 50/60Hz
- Rated operational current: 40A (AC-3)
- Mounting: DIN rail or screw fixing
- Conforms to IEC 60947-4-1
- Mechanical durability: 10 million operations
- Electrical durability: 1.2 million operations (AC-3)
- Dimensions (H x L x W): 85mm x 100mm x 45mm
- Weight: 0.7 kg
Key Features
- 22kW power rating for robust motor control
- 3-pole configuration for three-phase applications
- 1 normally open (NO) and 1 normally closed (NC) auxiliary contact
- 240VAC coil voltage for standard control circuits
- Compact DIN rail mountable design
- Reliable performance for industrial environments
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with local electrical regulations and standards.
Applications
- Motor control in industrial automation
- Switching of lighting circuits
- HVAC systems
- Pumping stations
- General power distribution panels
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enables efficient energy management in industrial systems
- Supports automation for reduced manual intervention and energy waste
- Durable design reduces replacement frequency and electronic waste
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal SCHLC1D40U7 22kW 3P 1NO+1NC 240VAC contactor is available for immediate purchase. Ideal for industrial motor control, automation, and power distribution applications.
