240W Power Switch Flood Light | Tri-CCT | Photocell | IP66 Rated | by Ektor
The 240W Power Switch Flood Light is designed for outdoor lighting with adjustable tri-colour temperature options (3000K, 4000K, 5000K) and a built-in photocell for automatic operation. With an impressive total system efficiency of up to 173 lm/W and an IP66 rating for dust and water resistance, this flood light is perfect for commercial and industrial applications, ensuring safety and visibility in any environment.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Tri-CCT Flood Light, Adjustable LED Floodlight, Photocell Flood Light, Outdoor LED Flood Light
Technical Specifications
- Total system efficiency up to 173 lm/W
- Power options: 120W, 160W, 240W with tri-CCT (3000K, 4000K, 5000K)
- Input voltage: 230Vac (216-253Vac range)
- Surge protection: 4kV L-N and 4kV L/N-PE
- Inrush current: 50A for 240W model
- Inrush duration: 200 microseconds (50%)
- Power factor: 0.95
- Colour rendering index (CRI): >70
- Beam angle: 120°
- Driver type: Fixed output, constant current, integrated
- Wiring: Flying leads (3 wire), 1500 mm length
- Operating temperature: up to 50°C
- IP rating: IP66
- IK rating: IK08
- Body material: Aluminium with powdercoated finish
- Diffuser material: Glass
- Installation type: Surface mount
- Switch type: Inline
- Dimensions (H x L x W): 250mm x 400mm x 350mm
- Weight: 6 kg
Key Features
- High total system efficiency up to 173 lm/W
- Adjustable flood light with tri-colour temperature (3000K, 4000K, 5000K)
- IP66 rated for dust and water resistance
- IK08 impact resistance
- Powdercoated black aluminium body with glass diffuser
- Surface mount installation
- Inline switch type with 1500 mm flying leads
- Surge protection of 4kV L-N and L/N-PE
- Power factor of 0.95
- Constant current fixed output integrated driver included
- Operating temperature up to 50°C
- Beam angle of 120°
- Colour rendering index (CRI) greater than 70
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended to ensure compliance with electrical standards and optimal performance.
Applications
- Outdoor lighting for commercial and industrial areas
- Security lighting
- Sports fields and recreational areas
- Building facades and architectural lighting
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
- AS/NZS 60598 – Luminaires Safety Standards
Environmental Benefits
- High efficiency LED technology reduces energy consumption.
- Long lifespan reduces waste and replacement frequency.
- Surge protection enhances durability and reduces electronic waste.
Warranty Information
5 years return to base warranty for commercial use.
Available Now
The Ektor 240W Power Switch Flood Light with Photocell and Tri-CCT is available now for immediate purchase. Ideal for commercial and industrial outdoor lighting applications.
