3W 24 Volt DC LED Shelf Light | Dual CCT | IP54 Rated | Dimmable | by atom
The 3W 24 Volt DC LED Shelf Light is perfect for both residential and commercial applications, featuring dual color temperatures of Warm White (3000K) and Cool White (4000K) with a luminous output of 300 lumens each. With an IP54 rating for dust and splash protection, this recessed light is designed for long-lasting performance, boasting an impressive LED lifetime of over 50,000 hours and a high efficiency of 100 lm/W.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: LED Shelf Light, Recessed LED Shelf Light, Dual CCT LED Shelf Light, 24V LED Shelf Light
Technical Specifications
- Power Wattage: 3W
- Input Voltage: 24V DC
- Colour Temperature: Warm White (3000K) and Cool White (4000K)
- Luminous Output: 300 lumens per CCT
- CRI: >80
- Beam Angle: 70°
- IP Rating: IP54 front face only
- LED Lifetime: >50,000 hours (TM-21 report)
- Macadam Steps: 5-step MacAdam Ellipse
- Dimmable: Yes
- Installation Type: Recessed
- Body Material: Aluminium
- Product Finish: Powder coated
- Working Temperature Range: 0 to 40 °C
- Driver Included: No
- Flex & Plug or Lead Length: 2000 mm
- Dimensions (H x L x W): 20mm x 30mm x 300mm
- Weight: 0.3 kg
Key Features
- Dual CCT: Warm White (3000K) and Cool White (4000K) with 300 lumens output each
- High total system efficiency of 100 lm/W
- IP54 rated front face for protection against dust and splashes
- Fixed adjustability with recessed installation
- Dimmable for customizable lighting ambiance
- Long LED lifetime of over 50,000 hours
- Colour Rendering Index (CRI) greater than 80 for accurate colour representation
- Beam angle of 70° for focused illumination
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended to ensure compliance with electrical standards and safety.
Applications
- Residential: Kitchen shelves, display cabinets, wardrobes
- Commercial: Retail displays, office shelving, hospitality
- General: Accent lighting for indoor recessed installations
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
- AS/NZS 60598 – Luminaires Safety Standards
Environmental Benefits
- Energy-efficient LED technology reduces power consumption
- Long LED lifespan minimizes waste and replacement frequency
- Low heat emission contributes to reduced cooling energy needs
Warranty Information
Standard manufacturer warranty applies. Please refer to Atom's warranty policy for details.
Available Now
The Atom 3W 24 Volt DC Constant Voltage LED Shelf Light is available for immediate purchase, ideal for recessed shelf lighting in residential and commercial applications.
