24V Modular Power Supply | 1.2A Output Current | DIN Rail Mount | Short Circuit Protection | @Pack of 1 | by Clipsal
The 24V Modular Power Supply delivers a reliable 1.2A output current, perfect for industrial automation and control panel applications. With a compact DIN rail mount design and built-in short circuit, overload, and overvoltage protection, it ensures safe and efficient operation. Ideal for both commercial and residential installations, this power supply features an LED status indicator for easy monitoring.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 24V Modular Power Supply | 1.2A Output Current | DIN Rail Mount | Short Circuit Protection | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHABLM1A24012
Alternatively Known As: 24V DIN Rail Power Supply, Modular Power Supply 24V, Clipsal 24V 1.2A Power Supply, SCHABLM1A24012, Industrial Power Supply 24V
Technical Specifications
- Input Voltage: 100-240V AC, 50/60Hz
- Output Voltage: 24V DC
- Output Current: 1.2A
- Mounting: DIN rail
- Protection: Short circuit, overload, overvoltage
- Operating Temperature: -20°C to +60°C
- Efficiency: >85%
- LED output status indicator
- Dimensions (H x L x W): 90mm x 60mm x 18mm
- Weight: 0.15 kg
Key Features
- Compact modular DIN rail mount design
- 24V DC output voltage
- 1.2A output current
- Short circuit, overload, and overvoltage protection
- High efficiency and low standby power consumption
- LED status indicator for output
Professional Installation Requirements
- Installation by a licensed electrician is required to ensure compliance with Australian electrical standards and safe operation.
Applications
- Industrial automation panels
- Building management systems
- Control cabinets
- Commercial and residential electrical installations
- LED lighting systems
Standards & Compliance
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- High efficiency reduces energy consumption and heat generation.
- Long operational life minimizes electronic waste.
- Compact design reduces material usage in installation.
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal Power Supply 24V 1.2A Modular SCHABLM1A24012 is available for immediate purchase. Ideal for industrial, commercial, and residential control panel applications.
