24VAC Contactor | 9A Rated Current | DIN Rail Mountable | High Endurance | @Quantity of 1 | by Clipsal
The 24VAC Contactor is designed for versatile control applications, featuring a 9A rated operational current and a compact DIN rail mountable design. Ideal for lighting control, HVAC systems, and motor control circuits, it ensures reliable switching for both resistive and inductive loads, making it perfect for commercial and industrial automation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 24VAC Contactor | 9A Rated Current | DIN Rail Mountable | High Endurance | @Quantity of 1 | by Clipsal
Brand: Clipsal
SKU: SCHLC1D098B7
Alternatively Known As: 24V AC Contactor, DIN Rail Contactor, Schneider LC1D09 Contactor, Control Contactor 24VAC, Industrial Contactor 24V
Technical Specifications
- Coil Voltage: 24VAC 50/60Hz
- Rated Operational Current: 9A (AC-3)
- Number of Poles: 3
- Mounting: DIN rail
- Auxiliary Contacts: 1 NO + 1 NC
- Electrical Endurance: 1,000,000 cycles
- Mechanical Endurance: 10,000,000 cycles
- Operating Temperature: -5°C to +60°C
- Standards: IEC 60947-4-1
- Dimensions (H x L x W): 80mm x 85mm x 45mm
- Weight: 0.4 kg
Key Features
- 24VAC coil voltage for versatile control applications
- Compact DIN rail mountable design
- High electrical and mechanical endurance
- Reliable switching for resistive and inductive loads
- Low power consumption coil
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with local wiring rules and standards.
Applications
- Lighting control in commercial and industrial buildings
- HVAC systems
- Motor control circuits
- Automation panels
- Switchboards
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enables efficient energy management by automating electrical loads
- Reduces manual switching, minimizing energy waste
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal SCHLC1D098B7 Contactor 24VAC is available for immediate purchase. Ideal for commercial and industrial automation, lighting, and HVAC control applications.
