24VDC Contactor | 9A Rated Current | 3 Poles & DIN Rail Mount | by Clipsal
The 24VDC Contactor is designed for reliable low-voltage control with a rated operational current of 9A and a compact design for space-constrained panels. Ideal for industrial automation, motor control centers, and HVAC systems, this contactor ensures high electrical and mechanical endurance, making it a perfect choice for various electrical switching applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 24VDC Contactor | 9A Rated Current | 3 Poles & DIN Rail Mount | by Clipsal
Brand: Clipsal
SKU: SCHLP1K09103BD3
Alternatively Known As: 24VDC Contactor, Clipsal Contactor 24VDC, SCHLP1K09103BD3, 24V DC Coil Contactor, Industrial Contactor 24VDC
Technical Specifications
- Coil Voltage: 24V DC
- Rated Operational Current: 9A (AC-3)
- Number of Poles: 3
- Auxiliary Contacts: 1 NO
- Mounting: DIN rail
- Frequency: 50/60Hz
- Insulation Voltage: 690V
- Mechanical Endurance: 10 million operations
- Electrical Endurance: 1 million operations
- Dimensions (H x L x W): 80mm x 85mm x 45mm
- Weight: 0.25 kg
Key Features
- 24V DC coil voltage for reliable low-voltage control
- Compact design suitable for space-constrained panels
- High electrical and mechanical endurance
- Suitable for switching AC and DC loads
- Easy DIN rail mounting
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with local electrical regulations and standards.
Applications
- Industrial automation panels
- Motor control centers
- Lighting control circuits
- HVAC systems
- General electrical switching applications
Standards & Compliance
- Complies with AS/NZS 60947 for low-voltage switchgear and controlgear
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Energy-efficient coil operation reduces power consumption
- Long operational life minimizes replacement waste
- RoHS compliant materials for reduced environmental impact
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal SCHLP1K09103BD3 Contactor 24VDC Coil is available for immediate purchase. Ideal for industrial and commercial control panel applications.
