25GBASE-LR SFP28 LC Transceiver Module | Single-Mode | 10KM Reach | Hot-Pluggable Design | by TP-LINK
The 25GBASE-LR SFP28 LC Transceiver Module is designed for high-speed connectivity, offering a single-mode fiber solution with a reach of up to 10 kilometers. Ideal for data centers and enterprise networks, this hot-pluggable transceiver supports Digital Diagnostic Monitoring (DDM) and is compatible with both 10G and 25G standards, ensuring efficient and reliable data transmission.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: 25G SFP28 Transceiver, 25GBASE-LR Module, Single-mode Fiber Transceiver, 10KM SFP28 Module
Technical Specifications
- Type: Single-mode SFP+/SFP28 LC Transceiver
- Reach: Up to 10 kilometers
- Power Consumption: ≤ 1.2 W
- Supports Digital Diagnostic Monitoring (DDM)
- Compatible with 10G and 25G SFP+/SFP28 MSA standards
- Hot-pluggable design
- Dimensions (H x L x W): 8mm x 56mm x 13mm
- Weight: 0.1 kg
Key Features
- Single-mode SFP+/SFP28 LC transceiver
- Hot-pluggable design for easy installation and replacement
- Supports Digital Diagnostic Monitoring (DDM) for real-time device monitoring
- Low power consumption not exceeding 1.2 W
- Compatible with 10G and 25G Small Form Pluggable Multi-Source Agreement (SFP+/SFP28 MSA)
Professional Installation Requirements
- Installation should be performed by qualified network technicians to ensure proper handling and configuration.
Applications
- Data centers and enterprise networks requiring high-speed 25G connectivity
- Switches with 25G ports such as SX6632YF
- Switches with 10G ports such as SG3428X and SG3452X
- Long-distance single-mode fiber optic communication up to 10 kilometers
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Low power consumption reduces energy usage and operational costs
- Supports efficient data transmission minimizing network equipment energy footprint
Warranty Information
3 years warranty provided by the manufacturer.
Available Now
The TP-LINK OMADA 25GBASE-LR SFP28 LC Transceiver Module is available for immediate purchase, ideal for upgrading network infrastructure to 25G speeds over long distances.
