26 Way Screw Terminal Block | 192mm Length | 100A Max | Brass & Zinc by Legrand
26 way screw terminal block with 192mm length and 100A max current—ideal for industrial and commercial electrical panels. Built for durability with brass and zinc-plated steel, ensuring reliable connections.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 26 Way Screw Terminal Block | 192mm Length | 100A Max | Brass & Zinc by Legrand
Brand: Legrand
SKU: 04807
Alternatively Known As: 26 Way Terminal Block, Screw Terminal Block 192mm, Electrical Distribution Terminal Block, Legrand Terminal Block
Technical Specifications
- Material: Brass and zinc-plated bichromated steel
- Voltage Rating: 400 V~
- Current Rating: 100 A max with 25 mm² input, 80 A max with 16 mm² input
- Number of Connections: 1 x 6 to 25 mm² + 25 x 1.5 to 16 mm²
- Screw Size: Ø M4
- Length: 192 mm
- Standard Compliance: IEC 60998-2-1
- Dimensions (H x L x W): 10.5mm x 6.5mm x 192mm
- Weight: 0.1 kg
Key Features
- Constructed from brass with zinc-plated bichromated steel for durability
- Compatible with universal terminal block supports for easy installation
- Supports up to 100 A max at 400 V~ with 25 mm² input
- Supports up to 80 A max at 400 V~ with 16 mm² input
- Conforms to IEC 60998-2-1 standard
- Number of connections: 1 x 6 to 25 mm² + 25 x 1.5 to 16 mm²
- Designed for use with Ø M4 screws
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical standards and safety.
Applications
- Electrical distribution and connection in industrial and commercial electrical panels
- Use in Plexo³ / HL and XL³ 125 enclosures for secure terminal connections
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable materials reduce the need for frequent replacements, minimizing waste
- Supports efficient electrical connections that reduce energy loss
Warranty Information
Standard manufacturer warranty applies. Please refer to Legrand for specific warranty details.
Available Now
The Legrand 26 Way Screw Terminal Block 192mm is available now for immediate purchase. Ideal for electrical distribution and connection applications in industrial and commercial settings.
