2D Barcode Scanner LBC621-17RB | 1.3 Megapixel CMOS Sensor | IP65 Rated | by SICK
The 2D Barcode Scanner LBC621-17RB features advanced 2D snapshot technology and a 1.3 Megapixel CMOS sensor, making it perfect for industrial barcode and 2D code scanning. With an IP65 rated aluminum housing, it ensures robust protection in harsh environments. Ideal for logistics, automated inspection, and quality control applications, this scanner supports a wide range of barcode types and offers Ethernet connectivity for seamless integration.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 2D Barcode Scanner LBC621-17RB | 1.3 Megapixel CMOS Sensor | IP65 Rated | by SICK
Brand: SICK
SKU: 1115469
Alternatively Known As: 2D Barcode Scanner, Industrial Barcode Reader, Snapshot Code Reader, SICK LBC621 Scanner
Technical Specifications
- Technology: 2D snapshot
- Light sources: Internal LEDs - red (617 nm ±15 nm), blue (470 nm ±15 nm), green feedback spot (525 nm ±15 nm), laser adjustment aid (630-680 nm)
- Laser class: 1, compliant with IEC 60825-1:2014
- Sensor: CMOS matrix, grayscale, 1.3 Megapixel (1280 x 1024 px)
- Spectral range: Approx. 400 nm to 900 nm
- Focal length: 17.1 mm
- Enclosure rating: IP65
- Protection class: III
- Power consumption: Typically 4 W
- Housing material: Aluminum die cast
- Output current: ≤ 100 mA
- Connections: 1 x M12 17-pin male connector, 1 x M12 4-pin female connector (Ethernet)
- Supply voltage: 12 V DC to 24 V DC ± 20%
- Window material: PMMA
- Supported barcode types: 2/5 Industrial, Interleaved 2 of 5, Codabar, Code 39, Code 93, Code 128, EAN-8, EAN-13, Pharmacode, GS1-128, Code 32, UPC-A, UPC-E, GS1, MSI
- Supported 2D codes: Data Matrix ECC200, QR code, Micro QR code, PDF417, Aztec
- OCR/OCV fonts: Universal, industrial, document, DotPrint, pharma, OCR-A, OCR-B, Arabic numbers
- Optical format: 1/1.8"
- Maximum encoder frequency: 300 Hz
- Ethernet: TCP/IP, EtherNet/IP, UDP, PROFINET
- Data transmission rate: 10/100 MBit/s
- Protocols: FTP, HTTP
- Operator interface: Web server
- Indicators: 5 status displays, 5 LED bar graph, 1 green/red feedback spot, beeper
- Operating temperature: -20 °C to +70 °C
- Storage temperature: -20 °C to +70 °C
- Shock and vibration: EN 60068-2-27, EN 60068-2-6
- Dimensions (H x L x W): 35.6mm x 71mm x 43mm
- Weight: 0.17 kg
Key Features
- 2D snapshot technology for fast and accurate code reading
- Adjustable electric focus with 17.1 mm focal length
- Multiple light sources including visible red, blue, and green LEDs
- Laser class 1 compliant with IEC 60825-1:2014 standards
- CMOS matrix sensor with 1.3 Megapixel resolution
- IP65 rated aluminum die cast housing for robust protection
- Supports a wide range of barcode and 2D code types
- Ethernet connectivity with TCP/IP, EtherNet/IP, UDP, PROFINET protocols
- Web server operator interface with optical and acoustic indicators
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with industrial sensor integration and electrical safety standards.
Applications
- Industrial barcode and 2D code scanning
- Automated inspection and quality control
- Logistics and warehouse management
- Pharmaceutical and document verification
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption at approximately 4 W reduces energy usage
- Durable IP65 rated housing extends product lifespan and reduces waste
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK LBC621-17RB 2D snapshot barcode scanner is available for immediate purchase, ideal for industrial automation, logistics, and quality control applications.
