2D Barcode Scanner LBC632 | CMOS Matrix Sensor | IP67 Rated | Adjustable Focus | by SICK
The 2D Barcode Scanner LBC632 features advanced 2D snapshot technology with a 1.9 Mpixel CMOS matrix sensor, making it perfect for industrial barcode and 2D code scanning. With an IP67 rated aluminum housing and adjustable manual focus, this scanner is built for durability and reliability in demanding environments like logistics and quality control.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 2D Barcode Scanner LBC632 | CMOS Matrix Sensor | IP67 Rated | Adjustable Focus | by SICK
Brand: SICK
SKU: 1091688
Alternatively Known As: 2D Barcode Scanner, Industrial Barcode Reader, 2D Code Reader, Snapshot Barcode Scanner
Technical Specifications
- Technology: 2D snapshot
- Sensor: CMOS matrix sensor, grayscale, 1.9 Mpixel (1600 x 1200 px)
- Spectral range: Approx. 400 nm to 900 nm
- Light source: Illumination LEDs (ordered separately), visible red laser alignment aid (λ = 630 nm to 680 nm)
- Laser class: Class 1, compliant with IEC 60825-1:2014 and FDA 21 CFR 1040.10
- Focus: Adjustable manually
- Lens: C-mount
- Enclosure rating: IP67
- Protection class: III (EN 60950-1)
- Power consumption: Typical 10 W ± 20%
- Supply voltage: 12 V DC to 24 V DC ± 20%
- Connections: Multiple M12 and M8 connectors for serial, I/O, voltage supply, Ethernet, and external illumination
- Data transmission rate: 10/100/1000 Mbit/s Ethernet
- Operating temperature: -20°C to +70°C
- Storage temperature: -20°C to +70°C
- Shock and vibration resistance: EN 60068-2-27 and EN 60068-2-6 compliant
- Dimensions (H x L x W): 46mm x 108mm x 63mm
- Weight: 0.43 kg
Key Features
- 2D snapshot technology with CMOS matrix sensor (1.9 Mpixel)
- Adjustable manual focus with C-mount lens
- Illumination LEDs and visible red laser alignment aid
- Supports multiple barcode types including Data Matrix ECC200, QR code, PDF417, and more
- Ethernet interface with TCP/IP, EtherNet/IP, UDP, PROFINET, FTP, HTTP support
- Robust IP67 rated aluminum die cast housing
- Wide operating temperature range from -20°C to +70°C
- Multiple optical and acoustic indicators for status feedback
- Image and data logging via microSD and external FTP
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper electrical connections and compliance with safety standards.
Applications
- Industrial barcode and 2D code scanning
- Automated inspection and quality control
- Logistics and warehouse management
- Pharmaceutical and document verification
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Durable IP67 housing reduces need for frequent replacements
- Energy-efficient operation with typical power consumption of 10 W
- Supports digital data logging reducing paper waste
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific terms and conditions.
Available Now
The SICK LBC632 2D Snapshot Barcode Scanner is available for immediate purchase, ideal for industrial and logistics applications requiring reliable barcode and 2D code reading.
