2D Barcode Scanner LBC642 | 1.7 Megapixel CMOS Sensor | IP65 Rated | by SICK
The LBC642 2D Barcode Scanner features advanced 2D snapshot technology and a 1.7 Megapixel CMOS sensor, making it perfect for industrial barcode and 2D code scanning. With an IP65 rating and a wide operating temperature range of -20°C to +70°C, this scanner is built for durability and reliability in demanding environments like manufacturing and logistics.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 2D Barcode Scanner LBC642 | 1.7 Megapixel CMOS Sensor | IP65 Rated | by SICK
Brand: SICK
SKU: 1091687
Alternatively Known As: 2D Barcode Scanner, Industrial Barcode Reader, 2D Code Reader, Snapshot Barcode Scanner
Technical Specifications
- Technology: 2D snapshot
- Light source: Illumination LEDs (ordered separately), laser alignment aid (visible red light 630-680 nm)
- Laser class: Class 1, compliant with IEC 60825-1:2014 and FDA 21 CFR 1040.10
- Sensor: CMOS matrix sensor, grayscale, 1.7 Megapixel (1600 x 1088 px)
- Spectral range: Approx. 400 nm to 900 nm
- Lens: C-mount
- Enclosure rating: IP65
- Protection class: III (EN 60950-1)
- Power consumption: Typically 10 W ± 20%
- Output current: ≤ 100 mA
- Connections: M12 17-pin male (serial, I/Os, voltage supply), M8 4-pin female (USB, not used), 2x M12 8-pin female (Gigabit Ethernet, one used)
- Supply voltage: 24 V DC ± 20%
- Window material: Glass
- Barcode types supported: 2/5 Industrial, Interleaved 2 of 5, Codabar, Code 39, Code 93, Code 128, EAN-8, EAN-13, Pharmacode
- 2D code types supported: Data Matrix ECC200, QR code, Micro QR code, PDF417, Aztec
- OCR/OCV fonts: Universal, industrial, document, DotPrint, pharma, OCR-A, OCR-B, Arabic numbers
- Optical format: 1 inch
- Maximum encoder frequency: 1 kHz
- Data transmission rate: 10/100/1000 Mbit/s
- Operator interface: Web server
- Data storage: Image and data logging via microSD and external FTP
- Ambient temperature operation: -20°C to +70°C
- Shock and vibration tested to EN 60068 standards
- Dimensions (H x L x W): 46mm x 142mm x 90mm
- Weight: 0.635 kg
Key Features
- 2D snapshot technology for high precision scanning
- Adjustable manual focus with C-mount lens
- CMOS matrix sensor with 1.7 Megapixels
- Supports multiple barcode types including Data Matrix ECC200, QR code, PDF417, and Aztec
- Ethernet connectivity with TCP/IP, EtherNet/IP, PROFINET, FTP, and HTTP support
- Robust aluminum die cast housing with IP65 rating
- Wide operating temperature range from -20°C to +70°C
- Integrated optical and acoustic indicators for status feedback
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper electrical connections and compliance with safety standards.
Applications
- Industrial barcode and 2D code scanning
- Quality control and inspection in manufacturing
- Logistics and warehouse management
- Pharmaceutical and document verification
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Durable design reduces replacement frequency and electronic waste
- Energy-efficient operation with typical power consumption of 10 W
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK LBC642 2D Snapshot Barcode Scanner is available for immediate purchase, ideal for industrial and manufacturing environments requiring reliable barcode and 2D code reading.
