2D Barcode Scanner LBC654 | 4.2 Mpixel CMOS Sensor | Adjustable Focus | IP65 Rated | by SICK
The 2D Barcode Scanner LBC654 features advanced 2D snapshot technology with a 4.2 Mpixel CMOS matrix sensor, making it perfect for industrial barcode scanning and automated inspection. With an adjustable manual focus and robust aluminum housing rated IP65, it operates efficiently in challenging environments from -20°C to +70°C. Ideal for logistics, quality control, and pharmaceutical applications, this scanner ensures reliable performance and durability.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Technology: 2D snapshot
- Sensor: CMOS matrix sensor, grayscale, 4.2 Mpixel (2048 x 2048 px)
- Spectral range: Approx. 400 nm to 900 nm
- Light source: Illumination LEDs (ordered separately), visible red laser alignment aid (630-680 nm)
- Laser class: Class 1, compliant with IEC 60825-1:2014 and 21 CFR 1040.10
- Focus: Adjustable manually
- Optical format: 1 inch
- Power consumption: Typical 10 W ± 20%
- Supply voltage: 24 V DC ± 20%
- Output current: ≤ 100 mA
- Connections: M12 17-pin male, M8 4-pin female (USB not used), M12 8-pin female (Gigabit Ethernet)
- Data transmission rate: 10/100/1000 Mbit/s
- Operating temperature: -20°C to +70°C
- Enclosure rating: IP65
- Housing material: Aluminum die cast
- Weight: 635 g
- Dimensions (H x L x W): 46mm x 142mm x 90mm
- Weight: 0.635 kg
Key Features
- 2D snapshot technology with CMOS matrix sensor, 4.2 Mpixel resolution
- Adjustable manual focus with C-mount lens
- Illumination LEDs and visible red laser alignment aid
- Supports multiple barcode types including Data Matrix, QR code, PDF417, and more
- Ethernet interface with TCP/IP, EtherNet/IP, PROFINET, FTP, HTTP support
- Robust aluminum die cast housing with IP65 rating
- Wide operating temperature range from -20°C to +70°C
- Integrated optical and acoustic indicators for status feedback
Professional Installation Requirements
- Installation by qualified personnel recommended to ensure proper electrical connections and compliance with safety standards.
Applications
- Industrial barcode and 2D code scanning
- Automated inspection and quality control
- Logistics and warehouse management
- Pharmaceutical and document verification
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Durable design reduces replacement frequency and electronic waste
- Energy-efficient operation with typical power consumption of 10 W
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK LBC654 2D Snapshot Barcode Scanner is available for immediate purchase, ideal for industrial and logistics applications requiring reliable barcode reading.
