2D Localization Sensor PLOC2D-621-17RB | 1280 x 1024 Resolution | IP65 Rated | by SICK
The 2D Localization Sensor PLOC2D-621-17RB offers high localization accuracy with a resolution of 1280 px x 1024 px, making it ideal for industrial automation and robotics applications. With a robust aluminum housing and IP65 rating, this sensor ensures durability and reliability in various environments. Its fast part localization time and support for multiple communication protocols enhance its versatility for quality control in manufacturing processes.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Sensor resolution: 1280 px x 1024 px (1.3 Mpixel)
- Working distance: 300 mm to 1500 mm
- Light sources: Visible red LED (617 nm), green LED (525 nm), blue LED (470 nm), and red laser (630-680 nm)
- Laser class 1 compliant with IEC 60825-1:2014 and FDA 21 CFR 1040.10
- Connection types: 1 x M12 17-pin male connector, 1 x M12 4-pin female Ethernet connector
- Supply voltage: 24 V ± 20%
- Power consumption: 4 W ± 20%
- Housing material: Aluminum die cast
- Enclosure rating: IP65
- Data transmission rate: 100 Mbit/s
- Protocols supported: TCP/IP XML and CSV, PROFINET, EtherNet/IP, FTP
- Operating temperature: 0 °C to +50 °C
- Storage temperature: -20 °C to +70 °C
- Shock and vibration tested to EN 60068-2-27 and EN 60068-2-6
- Dimensions (H x L x W): 35.6mm x 71mm x 43mm
- Weight: 0.17 kg
Key Features
- Stand-alone sensor with easy teach for localization of parts using 2D measurements
- Adjustable electric optical focus
- High localization accuracy of ± 0.5 px and ± 0.1° rotation
- Fast part localization time: < 0.5 seconds for first part, < 100 ms for additional parts
- Integrated optics and illumination with visible red, green, and blue LEDs
- Robust aluminum die cast housing with IP65 rating
- Supports multiple communication protocols including TCP/IP XML, CSV, PROFINET, EtherNet/IP, and FTP
- Data logging via microSD memory card and external FTP
- Web server user interface for easy configuration
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper electrical connections and compliance with safety standards.
Applications
- Industrial automation for part localization
- Robotics for precise 2D measurements
- Quality control in manufacturing processes
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Low power consumption of 4 W reduces energy usage
- Durable IP65 rated housing extends product lifespan and reduces waste
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK PLOC2D-621-17RB 2D Localization Sensor is available for immediate purchase, ideal for industrial automation and robotics applications.
