2D Localization Sensor PLOC2D-654C | 2048 x 2048 Resolution | IP65 Rated | by SICK
The 2D Localization Sensor PLOC2D-654C features a high-resolution 2048 x 2048 px sensor and adjustable optical focus, making it ideal for industrial automation and robotics applications. With a fast localization time of less than 0.5 seconds for the first part, this sensor ensures precise positioning and quality control in manufacturing environments. Its robust aluminum housing and IP65 rating provide durability and reliability in various conditions.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Sensor resolution: 2,048 px x 2,048 px (4.2 Mpixel)
- Optical focus: Adjustable manually
- Localization principle: Shape comparison
- Connection types: 1 x M12 17-pin male, 1 x M8 4-pin female (USB not used), 2 x M12 8-pin sockets (Gigabit Ethernet)
- Supply voltage: 24 V ± 20%
- Power consumption: 10 W ± 20%
- Housing material: Aluminum die cast
- Housing color: Light blue (RAL 5012)
- Enclosure rating: IP65
- Part localization time: < 0.5 seconds for first part, < 100 ms for additional parts
- Localization accuracy: ± 0.5 px, ± 0.1°
- Output data: X, Y (mm), rotation around Z (degrees)
- Data transmission rate: 100 Mbit/s
- Protocols supported: TCP/IP XML and CSV (robot), TCP/IP (operator), PROFINET, EtherNet/IP™, FTP
- User interface: Web server
- Data storage: microSD memory card and external FTP
- Operating temperature: 0 °C to +50 °C
- Storage temperature: -20 °C to +70 °C
- Shock and vibration: EN 60068-2-27 and EN 60068-2-6 compliant
- Dimensions (H x L x W): 106mm x 143mm x 90mm
- Weight: 0.635 kg
Key Features
- Stand-alone sensor with easy teach for localization of parts using 2D measurements
- High resolution 2,048 px x 2,048 px (4.2 Mpixel) sensor
- Adjustable manual optical focus
- Shape comparison localization principle
- Fast part localization time: < 0.5 seconds for first part, < 100 ms for additional parts
- Output data includes X, Y (mm) and rotation around Z (degrees)
- Robust aluminum die cast housing with IP65 rating
- Multiple connection options including M12 connectors and Gigabit Ethernet
- Supports TCP/IP XML, CSV, PROFINET, EtherNet/IP™, FTP protocols
- Web server user interface and microSD data logging
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper connection and configuration, especially for Ethernet and power supply interfaces.
Applications
- Industrial automation for part localization
- Robotics for precise positioning
- Quality control in manufacturing
- Large field of view 2D image analysis
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Energy efficient operation with 10 W power consumption
- Durable aluminum housing extends product life reducing waste
- Supports digital data logging reducing paper usage
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK PLOC2D-654C sensor is available for immediate purchase, ideal for industrial automation and robotics applications requiring precise 2D part localization.
