2D Snapshot Camera System PACS1000-321 | Ethernet & TCP/IP Connectivity | Integrated Illumination | by SICK
The PACS1000-321 2D snapshot camera system is designed for precise imaging in industrial automation and logistics. With Ethernet and RJ45 connectivity, it supports easy integration and configuration via a web interface. Ideal for pallet load inspection and quality control, this system enhances efficiency while reducing paper use through effective load documentation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Technology: 2D snapshot
- Supply voltage: 24 V DC (21.6 V DC to 26.4 V DC)
- Current consumption: Typically 2.834 A at 24 V (68.01 W)
- Typical object speed: 0.5 m/s
- Interfaces: Ethernet, RJ45, TCP/IP
- Export data format: FTP for images, TCP/IP for result logs
- Configuration interface: Web-Interface
- Operating ambient temperature: 0 °C to +40 °C
- Storage ambient temperature: 0 °C to +40 °C
- Dimensions (H x L x W): 200mm x 400mm x 300mm
- Weight: 5 kg
Key Features
- 2D snapshot technology for precise imaging
- Load documentation capability included
- Ethernet and RJ45 connectivity with TCP/IP support
- Web-interface for easy configuration
- Includes multiple cameras and lenses for versatile imaging
- Integrated illumination units for optimal image capture
Professional Installation Requirements
- Professional installation by qualified personnel is recommended to ensure proper setup and integration with existing systems.
Applications
- Industrial automation for pallet load inspection
- Logistics and warehouse load documentation
- Quality control in manufacturing processes
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Enables efficient load documentation reducing paper use
- Supports automation to reduce energy consumption in inspection processes
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK for detailed warranty terms.
Available Now
The SICK PACS1000-321 is available for immediate purchase, ideal for industrial and logistics applications requiring advanced load documentation and imaging.
