2D Snapshot Sensor | 12 Megapixel Resolution | IP65 Rated | Global-Shutter Technology | by SICK
The 2D Snapshot Sensor is equipped with a 12 Megapixel CMOS monochrome sensor, perfect for detecting standard objects and measuring dimensions in industrial automation. With a robust IP65-rated aluminum housing and high scan rate of 40 Hz, it ensures reliable performance in quality inspection applications. Ideal for professionals seeking precision and durability in their vision systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Sensor resolution: 4096 px x 3008 px (12 Megapixel)
- Pixel size: 2.74 µm x 2.74 µm
- Sensor size: 11.22 mm x 8.22 mm
- Working range: 500 mm to 2500 mm depending on lens
- Power consumption: Typical 24 W ± 20%
- Supply voltage: 24 V DC ± 20%
- Enclosure rating: IP65
- Connection types: Multiple M12 connectors for power, I/O, Ethernet, and illumination
- Scan/frame rate: 40 Hz
- Operating temperature: 0 °C to +50 °C
- Storage temperature: -20 °C to +70 °C
- Relative humidity: ≤ 90%, non-condensing
- EMC compliance: IEC 61000-6-2 and IEC 61000-6-4
- Shock and vibration resistance: EN 60068-2-27 and EN 60068-2-6
- Dimensions (H x L x W): 46mm x 143.3mm x 90mm
- Weight: 0.64 kg
Key Features
- 2D snapshot technology with 12 Megapixel CMOS monochrome sensor
- Programmable and configurable via SensorApp Nova Inspector
- Adjustable manual optical focus with C-mount lens option
- Global-Shutter shutter technology
- High scan/frame rate of 40 Hz
- Multiple Ethernet interfaces including PROFINET and EtherNet/IP™
- Robust aluminum die cast housing with IP65 rating
- LED feedback spot and laser alignment aid
- Supports SICK Nova Tool plug-in for custom tool development
- License included: Intelligent Inspection License with no time limit
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with industrial vision systems and electrical safety standards to ensure proper setup and compliance.
Applications
- Detecting standard objects
- Measuring dimension, contour, and volume
- Counting objects
- Identifying 2D codes, OCR, patterns, classification, and sorting
- Determining 2D position
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable aluminum housing ensures long product life reducing waste
- Energy-efficient 24 V DC operation minimizes power consumption
- Supports software updates and tool customization reducing need for hardware replacement
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK V2D8512P-1MCXXXAF0SXXXX 2D snapshot sensor is available for immediate purchase, ideal for industrial automation and quality inspection applications.
