2kVA 1.8kW Online UPS 1 Battery Bank Rack Tower Enduro

BRAND: CABAC
SKU: EN2-1-RT
$3,247.50 List price: $4,330.00
Free pick up (over 25 kg or over 1 meter)
Contact us for delivery cost
30 Days Return Electricians Unlock Trade Access
Enduro 2kVA 1.8kW online double conversion UPS features 1 battery bank and rack or tower mounting. Ideal for servers and sensitive IT loads.

Alternatively Known As: Enduro EN2000 UPS with EBM, 2kVA Rack/Tower UPS, Pure Sinewave Online UPS

Technical Specifications
  • Model: EN2-1-RT
  • Capacity: 2kVA / 1.8kW
  • Topology: Online double conversion
  • Input Voltage: 230V ±20%
  • Input Frequency: 45–65Hz
  • Phase: Single phase
  • Input Power Factor: ≥0.98
  • Output Voltage: 230VAC ±2%
  • Output Frequency in Battery Mode: 50Hz ±0.1Hz
  • Output Power Factor: 0.9
  • Output Waveform: Pure sinewave
  • Efficiency: 89% normal mode; up to 97% ECO mode
  • Battery Type: Sealed lead-acid, maintenance-free
  • Battery Configuration: 6 x 12V / 9Ah per standard UPS unit
  • Battery Bank: One external battery module included
  • Recharge Time: Approximately 5 hours to 90% capacity
  • Communications: USB and RS-232 standard; optional SNMP and relay cards
  • Protection: Surge protection, resettable circuit breaker, short-circuit protection and EPO
  • Noise Level: Less than 50dB at 1m
  • Mounting: Rack or tower
  • Rack Height: 2U UPS plus 2U battery module
  • Dimensions (H x L x W): 173mm x 710mm x 440mm
  • Weight: 59.3 kg
Key Features
  • Provides continuous power conditioning through online double-conversion technology
  • Pure sinewave output for servers, networking equipment and other sensitive IT loads
  • Rack-mountable or convertible to tower installation
  • Includes one external battery module for extended runtime
  • Interactive LCD display for load, battery, input, output and operating status
  • Supports optional SNMP and relay communication cards
  • Emergency power off function for rapid shutdown
  • Generator compatible
  • Runtime can be extended with additional battery modules
  • Includes RJ45 network and telephone line surge protection
Professional Installation Requirements
  • Installation, commissioning and connection to fixed electrical infrastructure should be performed by a suitably qualified electrical professional in accordance with the manufacturer's instructions, AS/NZS 3000 and applicable UPS safety requirements. Maintain suitable ventilation and allow for the combined weight of the UPS and battery module.
Applications
  • Server and data-room power protection
  • Network and telecommunications equipment
  • Point-of-sale systems
  • Security and camera-surveillance systems
  • Industrial control and automation equipment
  • Sensitive computer and electronic loads requiring regulated power
  • Telephone systems and communications equipment
Standards & Compliance
  • AS 62040.1: Uninterruptible power systems safety requirements, applicable to UPS equipment
  • AS IEC 62040.2: UPS electromagnetic compatibility requirements
  • AS IEC 62040.3: UPS performance and test requirements
  • AS/NZS 3000: Electrical installations requirements for fixed installation and wiring
  • Manufacturer literature identifies EN50091-2 and C-Tick/RCM EMC compliance; verify the current compliance marking on the supplied unit
Environmental Benefits
  • Online power conditioning can reduce equipment stress and help extend the service life of connected IT hardware
  • ECO operating mode can reduce UPS energy consumption where the connected load permits
  • Modular external battery design allows runtime capacity to be increased without replacing the UPS chassis
  • Maintenance-free sealed lead-acid batteries reduce routine servicing requirements
  • UPS batteries and electronic components should be recycled through approved e-waste and battery-recycling channels at end of life
Warranty Information

Standard PSS Distributors warranty: 2-year return-to-base warranty from the original purchase date, covering faults in materials or workmanship subject to the published warranty terms. Transportation to the service base is generally not covered.

Available Now

Available through ENDURO/PSS Distributors and authorised Australian distributors; confirm current stock and lead time before ordering.

UPS Sizing Calculator




This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
