2kVA 1.8kW Online UPS 3 Battery Banks Rack Tower Enduro

BRAND: CABAC
SKU: EN2-3-RT
$6,244.80 List price: $8,326.40
Free pick up (over 25 kg or over 1 meter)
Contact us for delivery cost
30 Days Return Electricians Unlock Trade Access
Enduro 2kVA 1.8kW online double conversion UPS features 3 battery banks and rack or tower mounting. Ideal for servers and sensitive IT loads.

Alternatively Known As: ENDURO EN2-3-RT, ENDURO 2kVA Online UPS, ENDURO Rack/Tower UPS, ENDURO UPS with 3 EBM

Technical Specifications
  • Model: EN2000 with three extended battery modules
  • Capacity: 2kVA / 1.8kW
  • Topology: Online double conversion
  • Input Voltage: 230V ±20%
  • Input Frequency Range: 45–65Hz
  • Phase: Single phase
  • Input Power Factor: ≥0.98
  • Output Voltage: 230VAC ±2%
  • Output Frequency on Battery: 50Hz ±0.1Hz
  • Output Power Factor: 0.9
  • Waveform: Pure sinewave
  • Total Harmonic Distortion: ≤3% linear load; ≤5% non-linear load
  • Output Sockets: 3 x Australian 3-pin sockets, including 2 critical and 1 non-critical outlets
  • Battery Type: Sealed lead-acid, maintenance-free
  • Standard UPS Battery Configuration: 6 x 12V 9Ah
  • Rated Battery Voltage: 72V
  • Extended Battery Configuration: UPS plus 3 EBMs; 63Ah total battery capacity
  • Recharge Time: Approximately 5 hours to 90%
  • Efficiency: ≥89% normal mode; up to 97% ECO mode
  • Communications: USB and RS-232 standard
  • Optional Management: SNMP and relay card
  • Protection: Resettable circuit breaker, surge protection, RJ45 network protection and EPO
  • Operating Temperature: 0–40°C
  • Operating Humidity: 0–95% non-condensing
  • Noise Level: <50dB at 1m
  • Mounting: 19-inch rack or tower
  • Rack Height: 2U per UPS or EBM module
  • Dimensions (H x L x W): 346mm x 710mm x 440mm
  • Weight: 125.3 kg
Key Features
  • Online double-conversion protection for servers and sensitive IT loads
  • Supplied with three extended battery modules for increased runtime
  • Rack-mountable or tower-configurable installation
  • Pure sinewave output suitable for sensitive electronic equipment
  • Interactive LCD display for load, battery, input, output and operating status
  • USB and RS-232 communication ports for monitoring and controlled shutdown
  • Optional SNMP network management and relay interfaces
  • Emergency Power Off function
  • Generator-compatible operation
  • Intelligent three-stage battery charging
Professional Installation Requirements
  • Installation, commissioning and battery connection should be performed by suitably qualified electrical or UPS service personnel in accordance with the installation manual and applicable Australian electrical requirements, including AS/NZS 3000 where permanent electrical installation work is involved.
Applications
  • Server rooms and data centres
  • Network switches, routers and telecommunications equipment
  • Sensitive IT and computer systems
  • Point-of-sale systems
  • Security and camera-surveillance systems
  • Telephone and communications systems
  • Industrial control and automation equipment
Standards & Compliance
  • AS IEC 62040.1: Uninterruptible power systems — general and safety requirements
  • AS IEC 62040.2: Uninterruptible power systems — electromagnetic compatibility requirements
  • AS IEC 62040.3: Uninterruptible power systems — method of specifying performance and test requirements
  • AS/NZS 3000: Applicable to associated fixed electrical installation, isolation and earthing work
Environmental Benefits
  • Three-stage charging and ECO mode can reduce operating energy consumption
  • Sealed lead-acid batteries are replaceable and recyclable through appropriate battery-recycling channels
  • Extended battery-module runtime can reduce equipment shutdowns and associated data loss
  • Rack or tower configuration supports long-term system integration and reduces premature equipment replacement
  • Repairable and serviceable design can extend operational life compared with disposable backup-power equipment
Warranty Information

Standard PSS Distributors warranty: 2-year return-to-base warranty from the original purchase date. Battery warranty conditions may differ and should be confirmed at purchase.

Available Now

Available through ENDURO and authorised Australian distributors; contact the distributor to confirm current stock and lead time.
