3 Phase Energy Meter | 3 Conductor/Four Conductor | Modbus Protocol | DIN Rail by NHP

BRAND: NHP

SKU: 48290110

$708.60 List price: $940.90

+ −

30 Days Return Delivery Options

3 phase energy meter with three conductor/four conductor capability and Modbus protocol support—ideal for industrial and commercial energy monitoring. Built for precise energy measurement, with DIN rail mounting for easy installation.

Description
Attachments

Product Name/Title: Socomec Digiware I-30 3Ph Energy Meter

Brand: NHP

SKU: 48290110

Alternatively Known As: Digiware Energy Meter, 3 Phase Energy Meter, Multifunction Measuring Instrument

Technical Specifications

Pole Type: Three conductor/four conductor
Ampere Meter: Yes
Supply Voltage: 24-24 V DC
Sampling Frequency: 10000 Hz
Number of Current Measurement Inputs: 3
Mounting Method: DIN rail
Degree of Protection: IP20
Operating Temperature: -10 to 70 °C
Storage Temperature: -25 to 70 °C
Dimensions (H x L x W): 90mm x 65mm x 18mm
Weight: 0.5 kg

Key Features

Three conductor/four conductor measurement capability.
Effective power measurement device.
Supports Modbus protocol for integration.

Professional Installation Requirements

Professional installation by a qualified electrician is recommended for optimal safety.

Applications

Industrial: Energy monitoring in manufacturing facilities
Commercial: Energy management in office buildings
General: Any application requiring precise energy measurement

Standards & Compliance

Complies with AS/NZS 60950 for safety and performance standards.

Environmental Benefits

Helps in reducing energy consumption and optimizing energy use.

Warranty Information

1 year warranty against manufacturing defects.

Available Now

The Socomec Digiware I-30 3Ph Energy Meter is available now for immediate purchase. Ideal for industrial and commercial energy monitoring.

48290110-AU-Energy-Meter-Datasheet.pdf (48290110-AU-Energy-Meter-Datasheet.pdf, 595 Kb) [Download]
