3 Phase Solid State Relay 530V | 25A Load Current | Zero-Crossing Switching | DIN Rail Mountable | @Pack of 1 | by Clipsal
The 3 Phase Solid State Relay 530V is designed for reliable switching in industrial automation systems, featuring a 25A load current and zero-crossing switching for enhanced performance. Ideal for motor control panels and HVAC equipment, this compact relay ensures silent operation with no moving parts, making it perfect for long-term use in demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 3 Phase Solid State Relay 530V | 25A Load Current | Zero-Crossing Switching | DIN Rail Mountable | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHSSP3A250BDR
Alternatively Known As: 3 Phase SSR, Three Phase Solid State Relay, Industrial Solid State Relay, Clipsal SSR 530V, SCHSSP3A250BDR
Technical Specifications
- Rated Voltage: 530V AC (maximum)
- Number of Phases: 3
- Control Voltage: 4-32V DC
- Load Current: 25A per phase
- Switching Type: Zero-crossing
- Mounting: DIN rail
- Input/Output Isolation: 4000V RMS
- LED status indicator
- Operating Temperature: -30°C to +80°C
- Dimensions (H x L x W): 90mm x 45mm x 105mm
- Weight: 0.5 kg
Key Features
- Three-phase solid state relay for reliable switching
- Rated for up to 530V AC operation
- No moving parts for silent operation and long service life
- Fast switching response
- Compact DIN rail mountable design
- LED status indicator for easy diagnostics
- High isolation between input and output
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with local electrical regulations and standards.
Applications
- Industrial automation systems
- Motor control panels
- HVAC equipment
- Pumps and compressors
- Heating elements
- Lighting control in commercial and industrial environments
Standards & Compliance
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Solid state design reduces mechanical wear and waste
- Energy-efficient operation with minimal heat generation
- Longer lifespan reduces replacement frequency and electronic waste
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal 3 Phase Solid State Relay 530V SCHSSP3A250BDR is available for immediate purchase. Ideal for industrial automation, motor control, and HVAC applications.
