3 Phase Solid State Relay 530V | 50A Load Current | Zero-Crossing Switching | DIN Rail Mountable | @Pack of 1 | by Clipsal
The 3 Phase Solid State Relay 530V is designed for high-reliability switching in industrial automation systems. With a load current of 50A per phase and zero-crossing switching technology, it ensures silent operation and long service life. Ideal for HVAC equipment and motor control panels, this compact relay features an integrated heat sink for efficient thermal management, making it a perfect choice for demanding applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 3 Phase Solid State Relay 530V | 50A Load Current | Zero-Crossing Switching | DIN Rail Mountable | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHSSP3A250B7RT
Alternatively Known As: 3 Phase SSR, Three Phase Solid State Relay, Industrial Solid State Relay, Clipsal SSR 530V, SCHSSP3A250B7RT
Technical Specifications
- Rated Voltage: 530V AC
- Number of Phases: 3
- Control Voltage: 90-280V AC/DC
- Load Current: 50A per phase
- Switching Type: Zero-crossing
- Mounting: DIN rail
- Integrated heat sink
- Operating Temperature: -30°C to +80°C
- Insulation Voltage: 4000V RMS
- Dimensions (H x L x W): 90mm x 45mm x 105mm
- Weight: 0.6 kg
Key Features
- Three-phase solid state relay for high-reliability switching
- Rated for up to 530V AC operation
- No moving parts for silent operation and long service life
- Fast switching response
- Compact DIN rail mountable design
- Integrated heat sink for efficient thermal management
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with local electrical regulations and standards.
Applications
- Industrial automation systems
- HVAC equipment
- Motor control panels
- Heating elements
- Pumps and compressors
Standards & Compliance
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Solid state design reduces mechanical wear and extends product lifespan
- Energy-efficient operation with minimal heat loss
- No arc emissions, reducing electrical noise and improving workplace safety
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal 3 Phase Solid State Relay 530V SCHSSP3A250B7RT is available for immediate purchase. Ideal for industrial automation, HVAC, and motor control applications.
