3 Pole Contactor 18.5kW | 110VAC Coil | 1NC Auxiliary | IP20 by NHP

BRAND: NHP
SKU: 100C37KD00
$610.60 List price: $810.80
+ −
30 Days Return Delivery Options
3 pole contactor with 18.5kW power rating and 110VAC coil—ideal for motor control and HVAC systems. Built for industrial and commercial use, with 1NC auxiliary contact and IP20 protection.

Product Name/Title: Allen-Bradley 100C Contactor 18.5kW 3Pole 110VAC 50 and 60Hz Coil 1NC Contact Auxiliary

Brand: NHP

SKU: 100C37KD00

Alternatively Known As: Power Contactor, AC Contactor, Motor Contactor

Technical Specifications
  • Number of Normally Open Contacts: 3
  • Number of Normally Closed Contacts: 0
  • Rated Operation Current at AC 3, 400V: 37 A
  • Rated Operation Power at AC 3, 400V: 20 kW
  • Rated Operation Current at AC 1, 400V: 65 A
  • Max Rated Operation Voltage: 690 V
  • Control Supply Voltage at AC 50 Hz: 110 V
  • Number of Auxiliary Contacts (NO): 0
  • Number of Auxiliary Contacts (NC): 1
  • Rated Operation Current at AC 3, 690V: 21 A
  • Rated Operation Power at AC 3, 690V: 18.5 kW
  • Rated Operation Power at AC 4, 400V: 6.3 kW
  • Control Supply Voltage at AC 60 Hz: 110 V
  • Power Consumption AC Coil Pickup: 105 VA
  • Power Consumption AC Coil Hold-in: 12.3 VA
  • Type of Electrical Connection: Screw connection
  • Rated Operation Current at AC 4, 400V: 14 A
  • Degree of Protection: IP20
  • Mounting Method: DIN-rail/screw
  • Dimensions (H x L x W): 81mm x 104mm x 45mm
  • Weight: 0.49 kg
Key Features
  • 3 Pole contactor with 1 NC auxiliary contact.
  • Rated for 18.5 kW at 400V.
  • Control supply voltage of 110V AC.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Industrial: Motor control applications
  • Commercial: HVAC systems
  • General: Automation and control systems
Standards & Compliance
  • Complies with AS/NZS 3000 for electrical installation standards.
Environmental Benefits
  • Efficient power management reduces energy consumption.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The Allen-Bradley 100C Contactor 18.5kW is available now for immediate purchase. Ideal for industrial and commercial applications.

Non-Returnable & Non-Cancellable

100C37KD00-AU-Contactor-18kW-3-Pole-Datasheet.pdf (100C37KD00-AU-Contactor-18kW-3-Pole-Datasheet.pdf, 276 Kb) [Download]
