3 Pole Contactor 5.5kW | 230VAC 50/60Hz | 1NC Auxiliary by NHP

BRAND: NHP
SKU: 100C12KF01
$180.50 List price: $239.70
+ −
30 Days Return Delivery Options
3 pole contactor with 5.5kW power and 230VAC 50/60Hz coil—ideal for motor control and automation systems. Built for industrial and commercial use, with 1NC auxiliary contact and IP20 protection.

Product Name/Title: Allen-Bradley 100C Contactor 5.5kW 3Pole 230VAC 50 and 60Hz Coil 1NC Contact Auxiliary

Brand: NHP

SKU: 100C12KF01

Alternatively Known As: Power Contactor, AC Contactor, 3 Pole Contactor

Technical Specifications
  • Number of normally open contacts: 3
  • Number of normally closed contacts: 0
  • Rated operation current at AC 3, 400 V: 12 A
  • Rated operation power at AC 3, 400 V: 5.5 kW
  • Rated operation current at AC 1, 400 V: 32 A
  • Max rated operation voltage: 690 V
  • Control supply voltage at AC 50 Hz: 230 V
  • Number of auxiliary contacts (NO): 0
  • Number of auxiliary contacts (NC): 1
  • Rated operation current at AC 3, 690 V: 7 A
  • Rated operation power at AC 3, 690 V: 5.5 kW
  • Rated operation power at AC 4, 400 V: 3 kW
  • Control supply voltage at AC 60 Hz: 230 V
  • Power consumption AC coil pickup: 75 VA
  • Power consumption AC coil hold-in: 9.5 VA
  • Type of electrical connection: Screw connection
  • Rated operation current at AC 4, 400 V: 6.6 A
  • Mounting method: DIN-rail/screw
  • Dimensions (H x L x W): 81mm x 86.5mm x 45mm
  • Weight: 0.39 kg
Key Features
  • 3 Pole contactor with 1 NC auxiliary contact.
  • Rated for 5.5 kW at 230 VAC.
  • IP20 protection rating.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Industrial: Motor control and automation systems
  • Commercial: HVAC systems, lighting control
Standards & Compliance
  • Complies with relevant Australian standards for electrical safety.
Environmental Benefits
  • Energy-efficient operation reduces overall power consumption.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The Allen-Bradley 100C Contactor 5.5kW 3Pole 230VAC is available now for immediate purchase. Ideal for industrial and commercial applications.

Non-Returnable & Non-Cancellable

100C12KF01-AU-Contactor-5kW-3-Pole-Datasheet.pdf (100C12KF01-AU-Contactor-5kW-3-Pole-Datasheet.pdf, 288 Kb) [Download]
