30mm HSM Core Drill | Ultra Thin Wall Design | Tungsten Carbide Tips | Rotary & Impact Mode | by Promac
The 30mm HSM Core Drill is engineered for SDS Plus machines, featuring an ultra-thin 2.5mm wall design and ultra-hard tungsten carbide tips for exceptional durability. Perfect for plumbing and electrical applications in masonry, this drill operates in both rotary and impact modes, ensuring efficient drilling through various materials like concrete and bricks. Ideal for professionals seeking speed and precision in their projects.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 30mm HSM Core Drill | Ultra Thin Wall Design | Tungsten Carbide Tips | Rotary & Impact Mode | by Promac
Brand: Promac
SKU: CL30S
Alternatively Known As: 30mm Core Drill Bit, SDS Plus Core Drill, Masonry Core Drill, HSM Core Drill
Technical Specifications
- Machine best suited for SDS Plus
- Core drill wall thickness: 2.5mm ultra thin wall
- Teeth material: Ultra hard tungsten carbide tips
- Operating action: Rotary and Impact mode or Rotary only mode
- Thread: M16 x 2.0
- Recommended speed: Larger diameter cores require slower speeds if speed regulation is possible
- Material recommendations: General concrete, hard bricks, soft bricks, lightweight blocks, natural stone, constructional granite, limestone
- Made in Sheffield, UK
- Dimensions (H x L x W): 100mm x 100mm x 30mm
- Weight: 0.3 kg
Key Features
- Rapid action core drill matched to SDS Plus machines
- Speeds up to 35% faster with minimal breakthrough
- Lightweight 2.5mm ultra thin wall design, 50% lighter than traditional core drills
- Unique Armeg original ball-locking & pilot drill system for quick pilot/arbor interchange
- Precision machined arbor flats for easy grip or spanner use
- Ultra hard tungsten carbide tips for increased wear resistance
- Machined Tommy Bar hole for easy disconnection of arbor and core drills
- Operates in rotary and impact mode or rotary only mode
Professional Installation Requirements
- Use by trained professionals with appropriate SDS Plus or Hex driven power tools is recommended for safety and optimal performance.
Applications
- Plumbing and electrical applications in brick, block, masonry
- Drilling waste pipes, water feed pipes, cable entry/exit
- Flue passage, extractor fans, exhausts, dust extractor ducting
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Lightweight design reduces material usage and energy consumption during use
- Durable tungsten carbide tips extend tool life, reducing waste
Warranty Information
Standard manufacturer warranty applies. Please refer to Promac warranty terms for details.
Available Now
The Promac 30mm HSM Core Drill is available now for immediate purchase. Ideal for professional plumbing, electrical, and construction drilling applications.
