MN 30V DC Undervoltage Release | Automatic Circuit Breaker Tripping | DIN Rail Mount | by Clipsal
The MN 30V DC Undervoltage Release is designed to enhance safety by automatically tripping circuit breakers when voltage drops below 70% of the rated value. Ideal for commercial and industrial switchboards, this device ensures reliable protection against undervoltage conditions, preventing equipment damage. Compatible with Clipsal and Schneider Electric circuit breakers, it offers easy integration and professional installation is recommended for optimal performance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: MN 30V DC Undervoltage Release | Automatic Circuit Breaker Tripping | DIN Rail Mount | by Clipsal
Brand: Clipsal
SKU: SCHLV429411
Alternatively Known As: Undervoltage trip, undervoltage release module, circuit breaker undervoltage release, SCHLV429411, Clipsal undervoltage release
Technical Specifications
- Rated voltage: 30V DC
- Device type: Undervoltage release
- Compatible with: Clipsal and Schneider Electric circuit breakers
- Mounting: DIN rail
- Operating temperature: -25°C to +70°C
- Trip threshold: Activates when voltage drops below 70% of rated value
- Dimensions (H x L x W): 85mm x 70mm x 18mm
- Weight: 0.15 kg
Key Features
- Undervoltage release for circuit breakers
- Operates at 30V DC
- Ensures automatic tripping of the circuit breaker when voltage drops below threshold
- Enhances safety by preventing equipment damage during undervoltage conditions
- Easy integration with compatible Clipsal and Schneider Electric devices
Professional Installation Requirements
- Installation must be performed by a licensed electrician to ensure compliance with safety standards and correct integration with circuit protection devices.
Applications
- Protection of electrical circuits in commercial and industrial switchboards
- Ensures safe disconnection of circuit breakers in the event of voltage drops
- Suitable for use with compatible Clipsal and Schneider Electric circuit breakers
Standards & Compliance
- Complies with AS/NZS 60947 for low-voltage switchgear and controlgear
Environmental Benefits
- Prevents equipment damage and potential energy waste by ensuring safe disconnection during undervoltage events
- Supports reliable operation of electrical systems, reducing risk of electrical faults and associated environmental hazards
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal MN 30V DC Undervoltage Release (SCHLV429411) is available for immediate purchase. Ideal for commercial and industrial switchboard applications requiring reliable undervoltage protection.
