36kV Tinned Mechanical Shear Lug 120-300mm² Bi-Metal Cabac
Tinned mechanical shear-bolt bi-metal lug, 120-300mm², rated up to 36kV, to IEC EN 61238-1-3, by Cabac.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Suitable for copper and aluminium conductors class 1, 2, and 5
- Cross-section range: 10 to 1000 mm²
- Voltage rating: up to 36kV
- Shearing bolts break at specified torque flush to connector body surface
- Shearing bolt tip rotates to reduce conductor damage
- Complies with IEC, EN 61238-1-3 2018 standards
- Dimensions (H x L x W): 50mm x 200mm x 150mm
- Weight: 1.5 kg
Key Features
- Bolt breaking place is repeatable flush with the outer surface of the connector body
- Compatible with copper and aluminium class 1, 2, and 5 connectors from 10 to 1000 mm²
- No damage to cable conductors during assembly
- Higher resistance to clamping force relaxation
- Reduction of partial discharges in connectors
- Significant reduction in the number of connector-pressing unit sets compared to traditional solutions
- Repeatability of cable connection system in terms of required clamping force
- Reduction of friction forces during installation, preventing damage to cable conductors
- Allows connection of class 5 flexible conductors without screw fittings
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended to ensure correct torque application and compliance with safety standards.
Applications
- Electrical power connectivity for copper and aluminium conductors
- Industrial and commercial electrical installations
- Connection of class 1, 2, and 5 conductors in power distribution systems
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Reduces waste by preventing damage to cable conductors during installation
- Enhances longevity of electrical connections reducing need for replacements
- Supports use of recyclable aluminium and copper materials
Warranty Information
Standard manufacturer warranty applies. Please refer to Cabac warranty terms for details.
Available Now
The Cabac Link Tinned Mechanical Shear 120-300SQMM is available now for immediate purchase. Ideal for electrical power connectivity applications requiring reliable and damage-free conductor connections.
