3kVA 2.7kW Online UPS 1 Battery Bank Rack Tower Enduro

BRAND: CABAC
SKU: EN3-1-RT
$3,899.60 List price: $5,199.50
Free pick up (over 25 kg or over 1 meter)
Contact us for delivery cost
30 Days Return Electricians Unlock Trade Access
Enduro 3kVA 2.7kW online double conversion UPS features 1 battery bank and rack or tower mounting. Ideal for servers and sensitive IT loads.

Alternatively Known As: EN3000 UPS, Enduro 3000VA UPS, 3kVA Rack-Mount UPS, 2.7kW Server UPS

Technical Specifications
  • Model: EN3000
  • Capacity: 3kVA / 2.7kW
  • Topology: Online double conversion
  • Input Voltage: 230V ±20%
  • Input Frequency Range: 45–65Hz
  • Phase: Single phase
  • Input Power Factor: ≥0.98
  • Input Protection: 15A resettable circuit breaker
  • Input Connection: IEC C20 16A
  • Output Voltage: 230VAC +1%/-2%
  • Output Frequency: 50Hz ±0.1Hz in battery mode
  • Output Power Factor: 0.9
  • Waveform: Pure sine wave
  • Output Sockets: 3 x Australian 3-pin sockets, 2 critical and 1 non-critical
  • Efficiency: ≥89% in normal mode; up to 97% in ECO mode
  • Battery Type: Sealed lead-acid, maintenance-free
  • Standard Battery Configuration: 6 x 12V / 9Ah
  • Rated Battery Voltage: 72V
  • Battery Bank: One internal battery string
  • Recharge Time: Approximately 5 hours to 90%
  • Battery Charging: Intelligent three-stage charging
  • Communications: USB and RS-232
  • Optional Communications: SNMP and relay card
  • Protection: Surge, short-circuit, overload, EPO and network protection
  • Surge Protection: 2200 joules / 60,000 amps
  • Operating Temperature: 0–40°C
  • Operating Humidity: 0–95% non-condensing
  • Noise Level: <50dB at 1m
  • Rack Height: 2RU
  • Dimensions (H x L x W): 86.5mm x 600mm x 440mm
  • Weight: 26.8 kg
Key Features
  • Online double-conversion technology for continuous power conditioning
  • Pure sine-wave output for servers and sensitive IT equipment
  • 3kVA / 2.7kW capacity
  • Rack or tower mounting configuration
  • Standard internal 72V sealed lead-acid battery bank
  • Interactive LCD display for load, battery, input, output and operating status
  • Emergency power off function
  • USB and RS-232 communications for monitoring and controlled shutdown
  • Optional SNMP and relay communications
  • Generator compatible
  • Australian 3-pin output sockets with separate critical and non-critical outlets
Professional Installation Requirements
  • Installation and commissioning should be performed by suitably qualified electrical or UPS service personnel. Connect only to an earthed supply and follow the manufacturer's instructions and applicable Australian wiring requirements. Battery servicing and replacement should be carried out by trained personnel using appropriate PPE.
Applications
  • Server rooms and data cabinets
  • Network and telecommunications equipment
  • Sensitive IT and electronic loads
  • Point-of-sale systems
  • Industrial control and automation equipment
  • Security and camera-surveillance systems
  • Telephone systems requiring conditioned backup power
Standards & Compliance
  • AS 62040.1:2019 is the applicable Australian UPS safety standard for low-voltage UPS with energy storage; product certification status was not independently verified.
  • Installation should comply with AS/NZS 3000 requirements for electrical installations where applicable.
Environmental Benefits
  • Sealed lead-acid batteries can be recovered and recycled through appropriate battery-recycling channels.
  • Replaceable battery construction can extend the service life of the UPS and reduce electronic waste.
  • ECO mode can reduce energy consumption when operating conditions permit.
  • Power conditioning and high normal-mode efficiency can help reduce losses in protected IT systems.
Warranty Information

PSS Distributors' standard warranty is a 2-year return-to-base warranty from the original purchase date, subject to its warranty terms and conditions. Transportation costs are generally excluded.

Available Now

Available through ENDURO/PSS Distributors and authorised Australian distributors; confirm current stock and lead time before ordering.

UPS Sizing Calculator




This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
