3kVA 2.7kW Online UPS 12x 120Ah Battery Bank Tower Enduro

BRAND: CABAC
SKU: EN3-120-12T
$15,358.20 List price: $20,477.60
Free pick up (over 25 kg or over 1 meter)
Contact us for delivery cost
30 Days Return Electricians Unlock Trade Access
Enduro 3kVA 2.7kW online double conversion UPS features 12x 120Ah battery bank, 10 year design life batteries and tower mounting. Ideal for servers.

Alternatively Known As: Enduro 3kVA Long Run UPS, Enduro 3000VA Online UPS, 3kVA Double-Conversion UPS, Server UPS with External Battery Bank

Technical Specifications
  • Capacity: 3kVA / 2700W
  • Topology: Online double conversion
  • Input Voltage: 230V ±20%
  • Input Frequency: 45–65Hz
  • Phase: Single phase
  • Input Protection: 15A breaker
  • Input Connection: IEC C20 16A
  • Output Voltage: 230VAC ±2%
  • Output Frequency on Battery: 50Hz ±0.1Hz
  • Output Power Factor: 0.9
  • Output Waveform: Pure sinewave
  • Output Connections: 3 x Australian three-pin sockets, including 2 critical and 1 non-critical outlet
  • Battery Type: Sealed lead-acid, maintenance-free VRLA
  • Battery Bank: 12 x 120Ah batteries
  • Battery Design Life: 10-year design-life battery option
  • Recharge Time: Approximately 5 hours to 90%
  • Efficiency: At least 89% in normal mode; up to 97% in ECO mode
  • Communications: USB and RS-232; optional SNMP and relay cards
  • Display: LCD display for load, battery, input, output and operating status
  • Protection: 2200 joule surge protection, network protection and resettable short-circuit breaker
  • Operating Temperature: 0–40°C
  • Operating Humidity: 0–95% relative humidity, non-condensing
  • Noise Level: Less than 50dB at 1m
  • Mounting: Tower UPS control unit with free-standing external battery bank
  • Dimensions (H x L x W): 1230mm x 780mm x 600mm
  • Weight: 400 kg
Key Features
  • Provides continuous online double-conversion power conditioning for servers and other critical IT equipment
  • Pure sinewave output suitable for sensitive electronic loads
  • 2700W output capacity with 3kVA VA rating
  • Includes a large-capacity 12 x 120Ah external sealed lead-acid battery bank
  • 10-year design-life batteries support extended service intervals compared with standard UPS batteries
  • Australian 230V single-phase input and output configuration
  • Generator-compatible design
  • LCD status display and audible alarms for battery, overload and fault conditions
  • USB and RS-232 communications included
  • Optional SNMP and relay communications for network monitoring and building-management integration
  • Tower-mount UPS control unit with floor-standing battery cabinet
Professional Installation Requirements
  • Installation, commissioning and battery connection should be performed by a suitably qualified electrical or critical-power technician. Follow the manufacturer's installation instructions and applicable Australian electrical requirements, including AS/NZS 3000 and relevant UPS and battery safety requirements. The battery bank is heavy and requires appropriate lifting, ventilation, isolation and overcurrent protection.
Applications
  • Server rooms and small data centres
  • Network and telecommunications equipment
  • Security, access-control and surveillance systems
  • Industrial control and automation systems
  • Medical, laboratory and other sensitive electronic equipment
  • Business-critical workstations and storage systems
  • Applications requiring extended runtime during mains outages
Standards & Compliance
  • AS 62040.1:2019 – relevant Australian safety standard for uninterruptible power systems; product-specific certification was not located
  • AS IEC 62040.3 – relevant performance and test standard for UPS systems
  • AS/NZS 3000:2018 – applicable to fixed electrical installation, isolation, earthing and wiring
  • AS/NZS 4836 – relevant safe-working requirements for work on or near low-voltage electrical installations
Environmental Benefits
  • Sealed lead-acid batteries are recyclable through appropriate battery-recycling programs
  • 10-year design-life batteries can reduce battery replacement frequency and associated waste compared with shorter-life alternatives
  • Online power conditioning can help protect connected equipment and extend service life
  • High ECO-mode efficiency of up to 97% can reduce energy losses during suitable operating conditions
Warranty Information

Warranty registration is provided through the Enduro/PSS distributor, but a specific warranty duration for this model was not publicly stated. Confirm current warranty terms with the authorised Australian distributor before purchase.

Available Now

Available through ENDURO/PSS and authorised Australian distributors, subject to current distributor stock and configuration availability.

UPS Sizing Calculator




This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
