3kVA 2.7kW Online UPS 3 Battery Banks Rack Tower Enduro
Enduro 3kVA 2.7kW online double conversion UPS features 3 battery banks and rack or tower mounting. Ideal for servers and sensitive IT loads.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Enduro 3000VA Online UPS, Enduro 3kVA Pure Sinewave UPS, EN3000 Rack/Tower UPS
Technical Specifications
- Capacity: 3kVA / 2.7kW
- Topology: Online double conversion
- Input Voltage: 230V ±20%
- Input Frequency: 45–65Hz
- Input Phase: Single phase
- Input Power Factor: ≥0.98
- Input Connection: IEC C20 16A
- Output Voltage: 230VAC ±2%
- Output Frequency on Battery: 50Hz ±0.1Hz
- Output Power Factor: 0.9
- Waveform: Pure sinewave
- Total Harmonic Distortion: ≤3% linear load; ≤5% non-linear load
- Output Connections: 3 × Australian 3-pin outlets, including two critical-load outlets
- Battery Type: Sealed lead-acid, maintenance-free
- Battery Voltage: 72V
- Battery Configuration: Three external battery banks
- Recharge Time: Approximately 5 hours to 90%
- Efficiency: ≥89% normal mode; up to 97% ECO mode
- Communications: USB and RS-232 standard; optional SNMP and relay cards
- Protection: 2,200 joules surge protection, resettable circuit breaker and EPO
- Operating Temperature: 0–40°C
- Noise Level: <50dB at 1m
- Rack Height: 2U
- Dimensions (H x L x W): 86.5mm x 600mm x 440mm
- Weight: 26.8 kg
Key Features
- True online double-conversion protection for servers and sensitive IT equipment
- Pure sinewave output with regulated 230VAC supply
- Rack-mountable or tower-mountable UPS control unit
- Three external battery banks for extended runtime
- Interactive LCD status display
- Generator compatible
- Emergency power-off function
- Critical and non-critical output load segmentation
- USB and RS-232 monitoring interfaces
- Optional SNMP and relay communications
- Expandable runtime through external battery modules
Professional Installation Requirements
- Installation and commissioning should be completed by a suitably qualified electrical or UPS technician. Mains connections and external battery-bank wiring must comply with applicable Australian electrical requirements, including AS/NZS 3000 and the manufacturer’s installation instructions.
Applications
- Server rooms and data centres
- Network and telecommunications equipment
- Security, surveillance and access-control systems
- Point-of-sale systems
- Industrial control equipment
- Sensitive office and business IT loads
Standards & Compliance
- AS 62040.1: applicable Australian safety standard for uninterruptible power systems; confirm the model-specific declaration of conformity before installation
- RCM/C-Tick EMC compliance is stated in Enduro product documentation
Environmental Benefits
- ECO mode can achieve up to 97% efficiency, reducing operating energy losses
- Replaceable and externally configurable battery banks can extend usable system life and reduce premature equipment replacement
- Sealed lead-acid batteries can be directed to approved battery recycling facilities at end of service life
- Extended runtime configuration supports continued operation of critical equipment during outages, helping reduce data loss and equipment disruption
Warranty Information
PSS Distributors’ standard warranty is a 2-year return-to-base warranty from the original purchase date, subject to its warranty terms and correct installation, operation and maintenance.
Available Now
Available through ENDURO/PSS distribution channels and authorised Australian UPS distributors; confirm current configuration and battery-bank availability before ordering.
UPS Sizing Calculator
This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
