3kVA 2.7kW Online UPS 4 Battery Banks Rack Tower Enduro

BRAND: CABAC
SKU: EN3-4-RT
$8,571.40 List price: $11,428.60
Free pick up (over 25 kg or over 1 meter)
Contact us for delivery cost
30 Days Return Electricians Unlock Trade Access
Enduro 3kVA 2.7kW online double conversion UPS features 4 battery banks and rack or tower mounting. Ideal for servers and sensitive IT loads.

Alternatively Known As: ENDURO EN3000 UPS, ENDURO Series III 3000VA UPS, Rack/Tower Online UPS

Technical Specifications
  • Capacity: 3,000VA / 2,700W
  • Topology: Single-phase online double conversion
  • Output Power Factor: 0.9
  • Input Voltage: 230V AC ±20%
  • Output Voltage: 230V AC ±2%
  • Output Waveform: Pure sinewave
  • Standard Battery Configuration: 6 x 12V 9Ah sealed lead-acid batteries
  • Rated Battery Voltage: 72V DC
  • Output Sockets: 3 x Australian 3-pin sockets, including 2 critical and 1 non-critical outlet
  • Efficiency: ≥89% normal mode; up to 97% ECO mode
  • Communications: USB and RS-232 standard; optional SNMP and relay card
  • Protection: 2,200 joule surge protection, resettable circuit breaker and emergency power off
  • Operating Temperature: 0°C to 40°C
  • Audible Noise: Less than 50dB at 1 metre
  • Runtime Expansion: Supports up to 4 external extended battery modules
  • Mounting: 2RU rack-mountable or tower configuration
  • Dimensions (H x L x W): 86.5mm x 600mm x 440mm
  • Weight: 26.8 kg
Key Features
  • Online double-conversion topology for continuous power conditioning
  • Pure sinewave output for servers and sensitive IT equipment
  • Rack or tower convertible design
  • Interactive LCD display for UPS status and operating information
  • Supports up to four external battery modules for extended runtime
  • Generator-compatible operation
  • Emergency power off function
  • Maintenance-free sealed lead-acid battery system
  • USB and RS-232 communications included
  • RJ45 network surge protection
Professional Installation Requirements
  • Installation and connection should be performed by a suitably qualified electrician or UPS technician in accordance with the manufacturer’s instructions and applicable Australian electrical requirements. Rack installation requires appropriate rack hardware, ventilation and load support.
Applications
  • Servers and network equipment
  • Data rooms and IT infrastructure
  • Telecommunications systems
  • Security and CCTV equipment
  • Point-of-sale systems
  • Industrial control equipment
  • Computer and office equipment requiring conditioned backup power
Standards & Compliance
  • AS 62040.1:2019 — Uninterruptible power systems (UPS), safety requirements
Environmental Benefits
  • Pure sinewave output and ECO mode can support efficient operation of connected equipment
  • Expandable battery architecture allows runtime to be sized to the application, potentially avoiding unnecessary battery capacity
  • Sealed lead-acid batteries are replaceable and recyclable through appropriate battery-recycling channels
  • Long service life and replaceable battery modules can reduce whole-unit replacement waste
Warranty Information

Standard 2-year return-to-base warranty from PSS Distributors, subject to proof of purchase, correct installation, operation within specified conditions and the supplier’s warranty terms. Batteries must be maintained and stored in accordance with the manufacturer’s requirements.

Available Now

Available through ENDURO/PSS and authorised Australian distributors; current stock and lead times should be confirmed before ordering.

UPS Sizing Calculator




This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
