3kVA 2.7kW Online UPS 48x 9Ah Battery Tower Plug and Play Enduro

BRAND: CABAC
SKU: EN3-9-48T
$6,696.70 List price: $8,928.90
Free pick up (over 25 kg or over 1 meter)
Contact us for delivery cost
30 Days Return Electricians Unlock Trade Access
Enduro 3kVA 2.7kW online double conversion UPS features 48x 9Ah battery tower and plug and play connection. Ideal for long run-time server loads.

Alternatively Known As: Enduro Long Run UPS, Enduro 3kVA Online UPS, EN3LR-9-48 UPS System, Server UPS with External Battery Cabinet

Technical Specifications
  • Model: EN3LR-9-48
  • Capacity: 3kVA / 2.7kW
  • Topology: Online double conversion
  • Input Voltage Range: 230V ±20%
  • Input Frequency Range: 45–65Hz
  • Input Phase: Single phase
  • Input Socket: IEC C20 16A
  • Input Breaker: 15A
  • Output Voltage: 230VAC ±2%
  • Output Frequency in Battery Mode: 50Hz ±0.1Hz
  • Output Power Factor: 0.9
  • Output Waveform: Pure sinewave
  • Output Sockets: 3 x Australian 3-pin sockets, including 2 critical and 1 non-critical outlets
  • Efficiency: ≥89% in normal mode; up to 97% in ECO mode
  • Battery Type: Sealed lead-acid, maintenance-free
  • Battery Configuration: 48 x 12V 9Ah batteries in external BB-192T battery cabinet
  • Nominal Battery Voltage: 192V DC
  • Battery Recharge Time: Approximately 5 hours to 90%
  • Communications: USB and RS-232
  • Optional Communications: SNMP and relay card
  • Display: Interactive LCD displaying load, battery, input, output and operating status
  • Surge Protection: 2200 joules / 60,000 amps
  • Environmental Operating Range: 0–40°C; 0–95% relative humidity, non-condensing
  • Noise Level: Less than 50dB at 1 metre
  • Mounting: UPS control unit supports rack or tower installation
  • Dimensions (H x L x W): 700mm x 635mm x 330mm
  • Weight: 165 kg
Key Features
  • Provides continuous power conditioning through online double-conversion technology
  • Includes an external BB-192T battery cabinet containing 48 x 12V 9Ah batteries
  • Designed for extended runtime applications and long-run server loads
  • Pure sinewave output suitable for servers, telecommunications, surveillance and industrial equipment
  • Interactive LCD status display
  • Three Australian 3-pin output sockets with separate critical and non-critical outlets
  • USB and RS-232 communication interfaces for monitoring and shutdown management
  • Optional SNMP and relay communications for network or building-management integration
  • Emergency Power Off function and resettable input protection
  • Generator-compatible operation
  • ECO mode available for improved operating efficiency
Professional Installation Requirements
  • Installation should be completed by a licensed electrician or suitably qualified UPS technician. The 16A supply, earthing, battery cabinet connection and final commissioning must comply with the manufacturer's instructions and applicable Australian electrical requirements. The battery cabinet is heavy and requires suitable lifting, positioning and ventilation arrangements.
Applications
  • Extended-runtime server and network equipment protection
  • Data rooms and telecommunications infrastructure
  • Security, CCTV and surveillance systems
  • Point-of-sale and business-critical computing equipment
  • Industrial control and automation systems
  • Facilities requiring conditioned, uninterrupted single-phase power
Standards & Compliance
  • AS 62040.1: relevant Australian safety standard for uninterruptible power systems
  • AS/NZS 3000:2018: applicable to fixed electrical installation, supply connection, isolation and earthing
  • RCM/C-Tick EMC marking is listed in the Enduro product documentation
Environmental Benefits
  • Maintenance-free sealed lead-acid batteries can be replaced individually and recycled through appropriate battery-recycling channels
  • Online power conditioning can reduce equipment stress and help extend the service life of connected IT equipment
  • ECO mode can reduce UPS operating losses where the connected load and power-quality conditions permit
  • Replaceable battery architecture can extend the usable life of the UPS and reduce whole-system replacement waste
Warranty Information

Standard PSS Distributors warranty: 2-year return-to-base warranty from the original purchase date, subject to proof of purchase and the published warranty conditions. Transportation, removal and reinstallation costs are excluded.

Available Now

Available through ENDURO/PSS channels and authorised Australian distributors; confirm current lead time and configuration before ordering.

UPS Sizing Calculator




This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
