3kVA 2.7kW Online UPS 6x 120Ah Battery Bank Tower Enduro

BRAND: CABAC
SKU: EN3-120-6T
$8,607.20 List price: $11,476.20
Free pick up (over 25 kg or over 1 meter)
Contact us for delivery cost
30 Days Return Electricians Unlock Trade Access
Enduro 3kVA 2.7kW online double conversion UPS features 6x 120Ah battery bank, 10 year design life batteries and tower mounting. Ideal for servers.

Alternatively Known As: Enduro 3kVA Online UPS, EN3LR-120-6, Enduro Long Run UPS, 3kVA Double-Conversion UPS

Technical Specifications
  • Model: EN3LR-120-6
  • UPS Capacity: 3kVA / 2.7kW
  • Topology: Online double conversion
  • Input Voltage: 230V ±20%
  • Input Frequency: 45–65Hz
  • Input Phase: Single phase
  • Input Protection: 15A circuit breaker
  • Input Connection: IEC C20 16A
  • Output Voltage: 230VAC ±2%
  • Output Frequency on Battery: 50Hz ±0.1Hz
  • Output Power Factor: 0.9
  • Output Waveform: Pure sine wave
  • Output Connections: 3 x Australian three-pin sockets; 2 critical and 1 non-critical
  • Efficiency: ≥89% normal mode; up to 97% ECO mode
  • Battery Configuration: 6 x 120Ah sealed lead-acid batteries in BB-A8T battery bank
  • Battery Type: Sealed, maintenance-free lead-acid
  • Battery Design Life: 10 years
  • Recharge Time: Approximately 5 hours to 90%
  • Communication: USB and RS-232 standard; optional SNMP and relay cards
  • Display: LCD status display
  • Protection: 2200 joules / 60,000 amps surge protection, resettable short-circuit breaker and EPO
  • Operating Temperature: 0°C to 40°C
  • Relative Humidity: 0–95%, non-condensing
  • Noise Level: <50dB at 1m
  • Runtime at Full Load: Approximately 143 minutes; runtime estimates vary by load and battery condition
  • Dimensions (H x L x W): 660mm x 780mm x 600mm
  • Weight: 200 kg
Key Features
  • Provides continuous online double-conversion power protection for sensitive loads
  • Includes a long-run external battery bank with six 120Ah batteries
  • 10-year design-life battery upgrade for extended service life
  • Pure sine-wave output suitable for servers, computers, telecommunications and industrial equipment
  • Three Australian three-pin output sockets with separate critical and non-critical outputs
  • Rack- or tower-mountable UPS control unit
  • Interactive LCD monitoring and USB/RS-232 communications
  • Optional SNMP and relay communications for network and building-management integration
  • Generator compatible with emergency power-off function
  • Fast recharge and scalable long-runtime configuration
Professional Installation Requirements
  • Installation and commissioning should be performed by a suitably qualified electrical contractor. The 200kg battery bank requires appropriate floor loading, secure positioning, ventilation, isolation, battery protection and safe handling. Electrical installation should comply with AS/NZS 3000 and the manufacturer's instructions. Battery maintenance and connection work should be completed by qualified personnel.
Applications
  • Server rooms and small data centres
  • Telecommunications and telephone systems
  • Computer and network equipment
  • Security and camera-surveillance systems
  • Point-of-sale systems
  • Industrial control and automation equipment
  • Other sensitive single-phase electrical loads requiring extended backup runtime
Standards & Compliance
  • AS IEC 62040.1: Uninterruptible power systems — general and safety requirements
  • AS IEC 62040.2: Uninterruptible power systems — electromagnetic compatibility requirements
  • AS IEC 62040.3: Uninterruptible power systems — performance and test requirements
  • AS/NZS 3000: Electrical installations — requirements for installation, wiring, isolation and earthing
Environmental Benefits
  • Sealed lead-acid batteries are recoverable through established battery recycling streams when correctly disposed of
  • 10-year design-life batteries can reduce replacement frequency and associated material waste compared with shorter-life alternatives
  • Online efficiency of up to 97% in ECO mode can reduce operating energy consumption under suitable load conditions
  • Replaceable battery-bank components can extend the usable service life of the UPS and reduce whole-unit replacement waste
Warranty Information

PSS Distributors' standard warranty is a 2-year return-to-base warranty from the original purchase date, subject to installation, operating-temperature, battery-maintenance and other warranty conditions. Transportation under the standard return-to-base warranty is not included. ([pssdistributors.com.au](https://www.pssdistributors.com.au/ups-warranty/))

Available Now

Available through PSS Distributors and authorised Australian electrical and data-equipment distributors; confirm current stock and lead time before ordering. ([pssdistributors.com.au](https://www.pssdistributors.com.au/p/power-supplies-batteries/uninterruptible-power-supplies/on-line-ups))

UPS Sizing Calculator




This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
