3kVA Online UPS with 48x 9Ah Battery Bank Plug and Play Enduro

BRAND: CABAC
SKU: EN3LR-9-48
$6,696.70 List price: $8,928.90
Free pick up (over 25 kg or over 1 meter)
Contact us for delivery cost
30 Days Return Electricians Unlock Trade Access
Enduro 3kVA online UPS features external battery bank with 48x 9Ah batteries, LCD screen and rack or tower control unit. Ideal for long run-time loads.

Alternatively Known As: Enduro Long Run Online UPS, Enduro 3kVA Double-Conversion UPS, EN3LR-9-48 UPS System

Technical Specifications
  • Capacity: 3kVA / 2700W
  • Topology: Online double conversion
  • Input Voltage: 230V ±20%
  • Input Frequency: 45–65Hz
  • Phase: Single-phase input and output
  • Output Voltage: 230V AC ±2%
  • Output Frequency in Battery Mode: 50Hz ±0.1Hz
  • Power Factor: 0.9
  • Waveform: Pure sinewave
  • External Battery Bank: BB-192T with 48 x 12V 9Ah sealed lead-acid batteries
  • Battery System Voltage: 48V DC
  • Battery Type: Sealed lead-acid, maintenance-free
  • Recharge Time: Approximately 5 hours to 90%
  • Efficiency: At least 89% in normal mode; up to 97% in ECO mode
  • Output Sockets: 3 x Australian 3-pin sockets, including two critical-load and one non-critical-load outlet
  • Communications: USB and RS-232 standard; optional SNMP and relay communications
  • Surge Protection: 2200 joules / 60,000 amps
  • Operating Temperature: 0–40°C
  • Operating Humidity: 0–95% non-condensing
  • Noise Level: Less than 50dB at 1m
  • Input Connection: IEC C20 16A
  • Display: LCD showing load, battery, input, output and operating status
  • Dimensions (H x L x W): 700mm x 635mm x 330mm
  • Weight: 165 kg
Key Features
  • Online double-conversion design for continuous conditioned power
  • 2700W real power capacity for servers, networking, security and control equipment
  • Large external 48 x 9Ah battery bank for extended runtime
  • Pure sinewave output suitable for sensitive electronic loads
  • Rack or tower-mountable UPS control unit
  • Interactive LCD status and diagnostic display
  • Three Australian 3-pin output sockets with critical-load segmentation
  • ECO mode for improved operating efficiency
  • USB and RS-232 monitoring connections included
  • Optional SNMP and relay cards for network or building-management integration
  • Generator-compatible operation
  • Emergency Power Off and resettable circuit-breaker protection
Professional Installation Requirements
  • Installation, commissioning and battery connection should be performed by a suitably qualified electrician or UPS technician. Follow AS/NZS 3000, the manufacturer's installation instructions and applicable battery-system safety requirements. The external battery bank is heavy and requires appropriate handling, ventilation, isolation and protection.
Applications
  • Server rooms and network infrastructure
  • Security, surveillance and access-control systems
  • Point-of-sale and business-critical electronic equipment
  • Industrial control and automation systems
  • Telecommunications and communications equipment
  • Data-room and plant-room loads requiring extended backup runtime
Standards & Compliance
  • AS IEC 62040.1: Applicable safety standard for uninterruptible power systems
  • AS IEC 62040.2: Applicable electromagnetic-compatibility standard for UPS equipment
  • AS IEC 62040.3: Applicable UPS performance and test-method standard
  • AS/NZS 3000: Applicable to the electrical installation, wiring, earthing and isolation of the UPS system
Environmental Benefits
  • ECO mode can reduce energy consumption during suitable mains conditions, with efficiency up to 97%
  • Sealed lead-acid batteries can be recovered through established battery recycling streams
  • Maintenance-free battery construction reduces routine servicing requirements
  • Extended runtime can reduce reliance on standby generators for short-duration outages
  • Replaceable battery-bank design can extend the service life of the UPS system and reduce equipment waste
Warranty Information

24-month warranty is listed for the EN3LR-9-48 product through Australian distribution channels; confirm current coverage, exclusions and battery warranty terms with the supplying distributor.

Available Now

Available through ENDURO/PSS and authorised Australian distributors; confirm current stock, lead time and battery-bank configuration before ordering.

UPS Sizing Calculator




This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
