3P Contactor 22kW | 110VAC Coil | 1NO & 1NC Auxiliary Contacts | by Clipsal
The 3P Contactor 22kW with a 110VAC coil is designed for reliable motor control in industrial automation. Featuring 1 normally open and 1 normally closed auxiliary contact, it ensures efficient switching of electrical power circuits. Ideal for HVAC systems, pumps, and compressors, this robust contactor is built to last with a mechanical life of 10 million operations.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 3P Contactor 22kW | 110VAC Coil | 1NO & 1NC Auxiliary Contacts | by Clipsal
Brand: Clipsal
SKU: SCHLC1D40F7
Alternatively Known As: 3 pole contactor, 22kW contactor, Clipsal contactor SCHLC1D40F7, 110V AC coil contactor, industrial contactor
Technical Specifications
- Number of Poles: 3
- Rated Power: 22kW (AC-3, 400V)
- Auxiliary Contacts: 1NO + 1NC
- Coil Voltage: 110VAC 50/60Hz
- Rated Operational Current: 40A (AC-3)
- Conforms to IEC 60947-4-1
- Mechanical Life: 10 million operations
- Electrical Life: 1.2 million operations (AC-3)
- Mounting: DIN rail or screw fixing
- Dimensions (H x L x W): 85mm x 100mm x 45mm
- Weight: 0.7 kg
Key Features
- 3 pole contactor for reliable switching
- 22kW power rating at 400V AC-3
- 1 normally open (NO) and 1 normally closed (NC) auxiliary contact
- 110VAC coil voltage for versatile control applications
- Compact and robust design for industrial environments
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with local electrical regulations.
Applications
- Motor control in industrial automation
- Switching and controlling electrical power circuits
- HVAC systems
- Pumps, compressors, and lighting circuits
Standards & Compliance
- Complies with AS/NZS 60947 for low-voltage switchgear and controlgear.
Environmental Benefits
- Enables efficient control of electrical loads, reducing unnecessary energy consumption.
- Durable design minimizes replacement frequency and electronic waste.
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
Available for immediate purchase. Ideal for industrial motor control, HVAC, and power switching applications.
