3P Contactor 4.0KW 24VDC Low Consumption | 3-Pole Design | High Endurance | by Clipsal
The 3P Contactor 4.0KW 24VDC Low Consumption is designed for efficient motor control and power switching in industrial applications. With a robust 3-pole design and rated for 4.0kW at 400V, it features a low consumption coil for energy efficiency. Ideal for HVAC systems and lighting control circuits, this contactor ensures high electrical and mechanical endurance, making it a reliable choice for commercial environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 3P Contactor 4.0KW 24VDC Low Consumption | 3-Pole Design | High Endurance | by Clipsal
Brand: Clipsal
SKU: SCHLP4K0901BW3
Alternatively Known As: 3 Pole Contactor, 4kW Contactor, 24VDC Contactor, Industrial Contactor, Motor Starter Contactor
Technical Specifications
- Number of Poles: 3
- Rated Operational Power: 4.0kW (AC3) at 400V
- Control Voltage: 24VDC (Low Consumption)
- Rated Operational Current: 9A (AC3)
- Auxiliary Contacts: 1 NO + 1 NC
- Electrical Endurance: 1,000,000 cycles
- Mechanical Endurance: 10,000,000 cycles
- Mounting: DIN rail or screw mounting
- Terminal Capacity: 1.5-4mm²
- Operating Temperature: -25°C to +60°C
- Dimensions (H x L x W): 80mm x 85mm x 45mm
- Weight: 0.35 kg
Key Features
- 3-pole contactor for reliable power switching
- Rated for 4.0kW (AC3) at 400V
- Low consumption 24VDC coil for energy efficiency
- Compact design for easy panel integration
- High electrical and mechanical endurance
- Screw terminal connections for secure wiring
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with local electrical regulations and standards.
Applications
- Motor control in industrial automation
- Lighting control circuits
- HVAC systems
- Pumping stations
- General power switching in commercial and industrial environments
Standards & Compliance
- Complies with AS/NZS 60947 for low-voltage switchgear and controlgear
Environmental Benefits
- Low consumption coil reduces energy usage
- Long operational life minimizes replacement waste
- RoHS compliant materials for reduced environmental impact
Warranty Information
12 months warranty against manufacturing defects.
Available Now
The Clipsal 3P Contactor 4.0KW 24VDC Low Consumption (SCHLP4K0901BW3) is available for immediate purchase. Ideal for industrial and commercial motor control and power switching applications.
