3P Contactor 5.5kW 230VAC 50 60Hz 1NC Auxiliary NHP
NHP Contactor AC Auxiliary features 12A, 5.5kW and 32A. Rated for 5.5kW at 230 VAC. IP20 protection rating. Ideal for motor control and automation systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Number of normally open contacts: 3
- Number of normally closed contacts: 0
- Rated operation current at AC 3, 400 V: 12 A
- Rated operation power at AC 3, 400 V: 5.5 kW
- Rated operation current at AC 1, 400 V: 32 A
- Max rated operation voltage: 690 V
- Control supply voltage at AC 50 Hz: 230 V
- Number of auxiliary contacts (NO): 0
- Number of auxiliary contacts (NC): 1
- Rated operation current at AC 3, 690 V: 7 A
- Rated operation power at AC 3, 690 V: 5.5 kW
- Rated operation power at AC 4, 400 V: 3 kW
- Control supply voltage at AC 60 Hz: 230 V
- Power consumption AC coil pickup: 75 VA
- Power consumption AC coil hold-in: 9.5 VA
- Type of electrical connection: Screw connection
- Rated operation current at AC 4, 400 V: 6.6 A
- Mounting method: DIN-rail/screw
- Dimensions (H x L x W): 81mm x 86.5mm x 45mm
- Weight: 0.39 kg
Key Features
- 3 Pole contactor with 1 NC auxiliary contact.
- Rated for 5.5 kW at 230 VAC.
- IP20 protection rating.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Motor control and automation systems
- Commercial: HVAC systems, lighting control
Standards & Compliance
- Complies with relevant Australian standards for electrical safety.
Environmental Benefits
- Energy-efficient operation reduces overall power consumption.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Allen-Bradley 100C Contactor 5.5kW 3Pole 230VAC is available now for immediate purchase. Ideal for industrial and commercial applications.
