3P NA Non-Automatic Trip Unit | 160A Rating | IEC 60947-3 Compliant | Compact Design | @Pack of 1 | by Clipsal
The 3P NA Non-Automatic Trip Unit is designed for reliable circuit isolation in commercial and industrial electrical distribution systems. With a 160A current rating and a compact NSX 160NA switch disconnector design, it ensures safe operation for medium to large loads. Ideal for switchboards and motor control centers, this unit is built to meet IEC 60947-3 standards, providing robust performance and durability.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 3P NA Non-Automatic Trip Unit | 160A Rating | IEC 60947-3 Compliant | Compact Design | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHLV430456
Alternatively Known As: 3 Pole Non-Automatic Trip Unit, NSX 160NA Switch Disconnector, 160A Switch Disconnector, LV430456, Schneider Non-Automatic Trip Unit
Technical Specifications
- Type: Non-Automatic Trip Unit
- Poles: 3
- Rated Current: 160A
- Device Application: Switch disconnector
- Mounting: Fixed
- Breaking Capacity: Not applicable (non-automatic)
- Standards: IEC 60947-3 compliant
- Operating Voltage: 690V AC max
- Utilization Category: AC-23A
- Terminal Connection: Screw terminals
- Dimensions (H x L x W): 161mm x 86mm x 105mm
- Weight: 2.5 kg
Key Features
- Non-automatic trip unit for enhanced circuit isolation
- 3 pole configuration for three-phase systems
- 160A current rating for medium to large loads
- Compact NSX 160NA switch disconnector design
- Robust construction for reliable performance
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 and local regulations.
Applications
- Commercial and industrial electrical distribution systems
- Switchboards and panelboards
- Main and sub-main circuit isolation
- Motor control centers
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enables safe and efficient electrical isolation, supporting system maintenance and reducing downtime.
- Durable design extends product lifespan, minimizing replacement waste.
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal 3P NA Non-Automatic Trip Unit SCHLV430456 is available for immediate purchase. Ideal for commercial and industrial electrical distribution systems requiring reliable circuit isolation.
