3P OLD Contactor 22KW | 1NO & 1NC Auxiliary Contacts | Robust Design | by Clipsal
The 3P OLD Contactor 22KW is designed for reliable industrial motor control, featuring 1 normally open and 1 normally closed auxiliary contact. With a rated operational power of 22kW at 400V AC-3, this contactor is perfect for HVAC systems, pumps, and lighting control. Its robust design ensures durability in heavy-duty applications, making it an ideal choice for automation panels and switchboards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 3P OLD Contactor 22KW | 1NO & 1NC Auxiliary Contacts | Robust Design | by Clipsal
Brand: Clipsal
SKU: SCHLC1D40E7
Alternatively Known As: Clipsal LC1D40E7, Schneider LC1D40E7, 22kW 3 Pole Contactor, Industrial Motor Contactor, 3P Contactor 22kW
Technical Specifications
- Number of Poles: 3
- Rated Operational Power: 22kW (AC-3, 400V)
- Auxiliary Contacts: 1 NO + 1 NC
- Coil Voltage: 220V 50Hz / 240V 60Hz
- Rated Current: 40A (AC-3)
- Mounting: DIN rail or screw
- Conforms to IEC 60947-4-1
- Mechanical Life: 10 million operations
- Electrical Life: 1.2 million operations (AC-3)
- Dimensions (H x L x W): 120mm x 130mm x 77mm
- Weight: 0.7 kg
Key Features
- Three-pole (3P) contactor for reliable switching
- Rated operational power: 22kW at 400V AC-3
- Includes 1 normally open (NO) and 1 normally closed (NC) auxiliary contact
- AC coil voltage: 220V 50Hz / 240V 60Hz
- Robust design for heavy-duty industrial applications
- DIN rail or screw mounting options
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with local electrical regulations and standards.
Applications
- Industrial motor control
- HVAC systems
- Pumps and compressors
- Lighting control
- Switchboards and distribution panels
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enables efficient energy management in industrial systems
- Supports automation for reduced manual intervention and energy waste
- Durable construction reduces replacement frequency and electronic waste
Warranty Information
12 months warranty against manufacturing defects.
Available Now
The Clipsal 3P OLD Contactor 22KW 1NO 1NC (SCHLC1D40E7) is available for immediate purchase. Ideal for industrial motor control, HVAC, and automation panels.
