3P OLD Contactor 25kW | 50A Rated Current | 110V AC Coil | by Clipsal
The 3P OLD Contactor 25kW is designed for reliable power switching in industrial applications, featuring a 50A rated current and a 110V AC coil voltage. Ideal for HVAC systems, motor control, and lighting panels, this contactor ensures efficient operation and compliance with IEC standards, making it a perfect choice for commercial environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 3P OLD Contactor 25kW | 50A Rated Current | 110V AC Coil | by Clipsal
Brand: Clipsal
SKU: SCHLC1D50F7
Alternatively Known As: Clipsal LC1D50F7, Schneider LC1D50F7, 3 Pole Contactor 25kW, Industrial Contactor 50A, 110V AC Coil Contactor
Technical Specifications
- Number of Poles: 3
- Rated Power: 25kW (AC3, 400V)
- Auxiliary Contacts: 1NO + 1NC
- Coil Voltage: 110V AC 50/60Hz
- Rated Current: 50A (AC3)
- Maximum Operating Voltage: 600V AC
- Conforms to IEC 60947-4-1
- Screw terminal connections
- Operating temperature: -5°C to +60°C
- Dimensions (H x L x W): 120mm x 130mm x 77mm
- Weight: 0.7 kg
Key Features
- Three-pole contactor for reliable power switching
- Rated for 25kW (AC3) at 400V
- 1 Normally Open (NO) and 1 Normally Closed (NC) auxiliary contact
- 110V AC coil voltage
- 50A rated current (AC3)
- 600V AC maximum operating voltage
- IEC compliant design for global compatibility
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with local electrical regulations and standards.
Applications
- Industrial motor control
- HVAC systems
- Lighting control panels
- Pumping stations
- General power switching in commercial and industrial environments
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enables efficient control of electrical loads, reducing unnecessary energy consumption
- Durable design minimizes replacement frequency and electronic waste
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal 3P Contactor 25kW 1NO 1NC 110V AC (SCHLC1D50F7) is available for immediate purchase. Ideal for industrial and commercial power switching applications.
