3P Reversing Contactor 2.2kW | 3-Pole Design | 1 NC Auxiliary Contact | 48V AC Coil | @Pack of 1 | by Clipsal
The 3P Reversing Contactor 2.2kW is designed for reliable motor direction control in industrial applications. With a robust 3-pole configuration and a 1 normally closed auxiliary contact, it ensures efficient operation for three-phase motors. Rated for 2.2kW at 400/415V and featuring a 48V AC coil, this contactor is perfect for automation panels, conveyor systems, and more.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 3P Reversing Contactor 2.2kW | 3-Pole Design | 1 NC Auxiliary Contact | 48V AC Coil | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHLC2K0601E7
Alternatively Known As: TeSys K reversing contactor, 3 pole reversing contactor, 2.2kW motor contactor, SCHLC2K0601E7, Clipsal reversing contactor
Technical Specifications
- Rated operational power: 2.2kW (AC-3) at 400/415V
- Rated operational current: 6A (AC-3) at 440V
- Number of poles: 3
- Auxiliary contacts: 1 NC
- Control voltage: 48V AC
- Utilization category: AC-3
- Mechanical durability: 10 million cycles
- Electrical durability: 1.2 million cycles (AC-3)
- Mounting: DIN rail or screw
- Standards: IEC 60947-4-1
- Dimensions (H x L x W): 58mm x 80mm x 45mm
- Weight: 0.3 kg
Key Features
- 3-pole reversing contactor for reliable motor direction control
- Rated for 2.2kW (AC-3) at 400/415V
- AC-3 utilization category up to 6A at 440V
- 1 normally closed (NC) auxiliary contact included
- 48V AC coil for control circuit compatibility
- Compact TeSys K series design for space-saving installation
- High electrical and mechanical endurance
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with local electrical regulations and standards.
Applications
- Industrial motor control
- Reversing applications for three-phase motors
- Automation panels
- Conveyor systems
- Pumps and fans
Standards & Compliance
- Complies with AS/NZS 60947 for low-voltage switchgear and controlgear
Environmental Benefits
- Enables efficient motor control, reducing unnecessary energy consumption
- Durable design minimizes replacement frequency and electronic waste
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal TeSys K 3P Reversing Contactor 2.2kW 1NC 48V AC Coil (SCHLC2K0601E7) is available for immediate purchase. Ideal for industrial motor control and automation applications.
