3P3D mA25 Trip Unit | 25A Rated Current | Thermal-Magnetic Protection | 3-Pole Design | @Pack of 1 | by Clipsal
The 3P3D mA25 Trip Unit is designed for reliable circuit protection in three-phase systems, featuring a 25A rated current and adjustable thermal-magnetic trip mechanism. Ideal for commercial and industrial applications, this robust unit ensures safety and performance in demanding environments, making it perfect for electrical distribution boards and switchboards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 3P3D mA25 Trip Unit | 25A Rated Current | Thermal-Magnetic Protection | 3-Pole Design | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHLV429122
Alternatively Known As: Clipsal SCHLV429122, 3 Pole 3 Phase Trip Unit, 25A Trip Unit, Clipsal Circuit Breaker Trip Unit
Technical Specifications
- Type: 3P3D mA25 Trip Unit
- Rated Current: 25A
- Poles: 3
- Trip Mechanism: Thermal-magnetic
- Voltage: 415V AC (typical for 3-phase applications)
- Mounting: DIN rail or panel mount
- Application: Circuit protection for three-phase systems
- Dimensions (H x L x W): 130mm x 80mm x 75mm
- Weight: 0.7 kg
Key Features
- Three-pole, three-phase design for comprehensive circuit protection
- Adjustable thermal-magnetic trip unit for precise overload and short-circuit protection
- 25A rated current for medium-load applications
- Robust construction for reliable performance in demanding environments
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with Australian standards and local regulations.
Applications
- Commercial and industrial electrical distribution boards
- Switchboards requiring adjustable trip protection
- Protection of three-phase electrical circuits
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enhances electrical safety, reducing risk of fire and equipment damage
- Durable design minimizes replacement frequency and electronic waste
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal 3P3D mA25 TRIP Unit SCHLV429122 is available for immediate purchase. Ideal for commercial and industrial switchboards requiring reliable three-phase circuit protection.
