3P3D TM63D TRIP Unit | 63A Thermal-Magnetic Protection | 3-Pole Compatibility | by Clipsal
The 3P3D TM63D TRIP Unit is a thermal-magnetic trip unit rated for 63A, designed for reliable circuit protection in commercial and industrial applications. Compatible with ComPact NSX 100/160/250 circuit breakers, it provides both overload and short-circuit protection, ensuring safety and efficiency in electrical distribution panels. Ideal for licensed electricians looking to upgrade or maintain existing systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 3P3D TM63D TRIP Unit | 63A Thermal-Magnetic Protection | 3-Pole Compatibility | by Clipsal
Brand: Clipsal
SKU: SCHLV429032
Alternatively Known As: TM63D Trip Unit, NSX Trip Unit, 63A Thermal Magnetic Trip Unit, ComPact NSX Trip Module, SCHLV429032
Technical Specifications
- Type: Thermal-magnetic trip unit
- Rated current: 63A
- Number of poles: 3
- Compatibility: ComPact NSX 100/160/250 circuit breakers
- Protection: Overload (thermal) and short-circuit (magnetic)
- Mounting: Direct fit for NSX series
- Dimensions (H x L x W): 120mm x 80mm x 75mm
- Weight: 0.6 kg
Key Features
- Thermal-magnetic trip unit for reliable circuit protection
- Rated for 63A, suitable for 3-pole, 3d (three-pole, three direct) applications
- Compatible with ComPact NSX 100/160/250 circuit breakers
- Provides both overload (thermal) and short-circuit (magnetic) protection
- Easy replacement and installation in existing NSX systems
Professional Installation Requirements
- Installation must be performed by a licensed electrician to ensure compliance with Australian standards and optimal safety.
Applications
- Commercial and industrial electrical distribution panels
- Switchboards for protection of circuits
- Upgrades and maintenance of ComPact NSX 100/160/250 circuit breakers
Standards & Compliance
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enhances electrical safety, reducing risk of fire and equipment damage
- Supports efficient energy management by preventing overloads and faults
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal 3P3D TM63D TRIP Unit (SCHLV429032) is available for immediate purchase. Ideal for commercial and industrial switchboards requiring reliable circuit protection.
