3P3T Micrologic 2.2 250A Circuit Breaker | 36kA Breaking Capacity | Compact NSX25 Frame | by Clipsal
The 3P3T Micrologic 2.2 250A Circuit Breaker is designed for commercial and industrial electrical distribution systems, featuring a high breaking capacity of up to 36kA at 415V AC. With its advanced Micrologic 2.2 electronic trip unit, it provides enhanced protection and monitoring, making it ideal for main and sub-main circuit protection in switchboards and panelboards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 3P3T Micrologic 2.2 250A Circuit Breaker | 36kA Breaking Capacity | Compact NSX25 Frame | by Clipsal
Brand: Clipsal
SKU: SCHLV431870
Alternatively Known As: NSX250N Circuit Breaker, Micrologic 2.2 250A, Schneider NSX250, 3P3T MCCB, SCHLV431870
Technical Specifications
- Number of Poles: 3
- Trip Unit: Micrologic 2.2 electronic
- Rated Current: 250A
- Frame Size: NSX25
- Breaking Capacity: Up to 36kA at 415V AC
- Standards: IEC 60947-2
- Mounting: Fixed
- Operating Voltage: 690V AC max
- Frequency: 50/60Hz
- Ambient Temperature: -25°C to +70°C
- Dimensions (H x L x W): 161mm x 86mm x 140mm
- Weight: 5.5 kg
Key Features
- 3-pole, 3-trip (3P3T) configuration for enhanced protection
- Micrologic 2.2 electronic trip unit for advanced protection and monitoring
- Rated current: 250A
- Compact NSX25 frame for space-saving installation
- High breaking capacity for reliable circuit protection
- Suitable for both AC and DC applications
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 and local regulations.
Applications
- Commercial and industrial electrical distribution systems
- Main and sub-main circuit protection
- Switchboards and panelboards
- Infrastructure and large building projects
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Improved energy efficiency through precise circuit protection
- Reduces risk of electrical fires and equipment damage
- Long service life minimizes replacement waste
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal 3P3T Micrologic 2.2 250A NSX25 Circuit Breaker (SCHLV431870) is available for immediate purchase. Ideal for commercial and industrial electrical distribution systems.
