4 C/O Miniature Plug-in Relay with LED | 24V DC Coil | 6A Contact Rating | by Clipsal
The 4 C/O Miniature Plug-in Relay with LED is designed for versatile switching in industrial automation and control applications. Featuring a 24V DC coil voltage and a robust 6A contact rating, this relay ensures reliable performance with an integrated LED indicator for coil status. Ideal for building management systems and control cabinets, it offers a long operational life and energy efficiency.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 4 C/O Miniature Plug-in Relay with LED | 24V DC Coil | 6A Contact Rating | by Clipsal
Brand: Clipsal
SKU: SCHRXM4AB2BD
Alternatively Known As: RXM4AB2BD relay, Harmony RXM relay, 4 pole changeover relay, 24VDC plug-in relay, Clipsal industrial relay
Technical Specifications
- Contact configuration: 4 C/O (4PDT)
- Coil voltage: 24V DC
- Contact rating: 6A at 250V AC/30V DC
- LED indicator: Yes (for coil status)
- Mechanical durability: 10,000,000 operations
- Electrical durability: 100,000 operations at rated load
- Mounting: Plug-in socket
- Insulation resistance: >100 MΩ at 500V DC
- Dielectric strength: 2,500V AC between coil and contacts
- Dimensions (H x L x W): 38mm x 35mm x 21mm
- Weight: 0.1 kg
Key Features
- 4 changeover (C/O) contacts for versatile switching
- 24V DC coil voltage
- Integrated LED indicator for coil status
- Miniature plug-in design for easy installation and replacement
- 6A contact rating for reliable performance
- Harmony RXM series for robust industrial use
Professional Installation Requirements
- Installation by a qualified electrician is recommended to ensure correct wiring and compliance with safety standards.
Applications
- Industrial automation panels
- Building management systems
- Control cabinets
- Switchboards
- General electrical switching applications
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Long operational life reduces replacement frequency and waste
- Low power consumption coil for energy efficiency
- RoHS compliant materials minimize environmental impact
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal Harmony RXM 4 C/O Miniature Plug-in Relay with LED 24VDC (SCHRXM4AB2BD) is available for immediate purchase. Ideal for industrial automation, control panels, and electrical switching applications.
