4 Door Access Controller | 100,000 User Capacity | TCP/IP & RS-485 Support | PoE Enabled by Dahua Technology
4 Door Access Controller with a 100,000 user capacity and TCP/IP & RS-485 support—ideal for commercial security management. Built for efficient access control, with PoE capability and robust alarm features for enhanced safety.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 4 Door Access Controller | 100,000 User Capacity | TCP/IP & RS-485 Support | PoE Enabled by Dahua Technology
Brand: Dahua Technology
SKU: ASC2204B-S
Alternatively Known As: 4 Door Access Controller, Master Access Controller, Dahua Access Control Panel
Technical Specifications
- Communication: TCP/IP, RS-485, Wiegand (W26 and W34)
- User Capacity: 100,000 users
- Record Storage: 500,000 card swiping records
- Alarm Types: Card reader tamper, intrusion, door sensor timeout, duress, illegal card threshold, incorrect password
- Time Sync: Built-in RTC with manual and auto synchronization
- Power Supply: Supports PoE
- Memory Protection: Power-off memory protection
- Upgrade: Online upgrade supported
- Watchdog: Supported
- Dimensions (H x L x W): 180mm x 50mm x 250mm
- Weight: 1.5 kg
Key Features
- Supports TCP/IP communication
- Dual communication protocols: RS-485 and Wiegand (W26 and W34)
- Capacity for 100,000 users and 500,000 card swiping records
- Supports interlock, group combination, anti-passback, remote unlock
- Multiple alarm supports including card reader tamper, intrusion, door sensor timeout, duress, illegal card threshold, and incorrect password
- Built-in RTC with manual and automatic time synchronization
- Power-off memory protection and online upgrade capability
- Watchdog support for system protection
- Supports PoE power supply
Professional Installation Requirements
- Professional installation by a qualified security systems technician or electrician is recommended to ensure proper integration and compliance with safety standards.
Applications
- Access control for commercial buildings
- Security management in offices and facilities
- Integration with security and alarm systems
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Supports PoE power supply reducing the need for additional power cables and lowering energy consumption
Warranty Information
3 years warranty covering manufacturing defects and hardware failures.
Available Now
The Dahua ASC2204B-S 4 Door 1-way Master Access Controller is available now for immediate purchase. Ideal for commercial and security access control applications.
